2015 SINOLIFT ESR Series Scale Pallet Truck in Good Quality
1)Features of ESR Series Scale Pallet Truck
· Pallet truck with scale
· Capacity:2000kg in 1 kg steps
· Tolerance: +/- 2 kg
· Scale functions: zero correction, gross/net weighing, total weight
· Power supply: 4×1.5V AA batetries
· Low battery warning + auto shut off function after 3 minutes
· Total fork width 570mm, width per fork 180mm, fork height 90mm, fork length 1150mm
· Polyurtane steering wheels and tandem fork rollers
· Water and dust proof to norm IP65
One of the most important characteristics for a reliable mobile scale. IP65 means that the pallet truck scale can be used outside or lorries and be cleaned with water (but not by high pressure !!!) The load cells in the forks have an even higher protection level.
2)Specifications of ESR Series Scale Pallet Truck
| 1KG=2.2LB 1INCH=25.4MM | ||||
| Item/Type | HP ESR20 | HP ESR20/L | ||
| Capacity Q | kg | 2000 | 2000 | |
| Min.fork height H1 | mm | 85 | 75 | |
| Max.fork height H2 | mm | 200 | 190 | |
| Steering wheel D | mm | Φ180×50 | Φ180×50 | |
| Tanden | mm | Φ74×70 | Φ64×70 | |
| Size of fork C×H | mm | 182×50 | 182×50 | |
| Width overall forks B | mm | 555/690 | 570/690 | |
| Fork length I | mm | 1150/1220 | 1150/1220 | |
| Overall length A1 | mm | 1580/1650 | 1580/1650 | |
| Battery | mm | DC 1.5V×4 | DC 1.5V×4 | |
| Optional | Thermal Printer | |||
3)Pictures of ESR Series Scale Pallet Truck
4)Workshop of ESR Series Scale Pallet Truck
5)Certificates of ESR Series Scale Pallet Truck
6)Terms and Service of ESR Series Scale Pallet Truck
| Lead time | 3-4 weeks |
| Packing | Standard export fumigated wooden pallet, foam rubbers |
| Payment term | T/T payment in advance; L/C at sight |
| Lead term | FOB Shanghai or CFR/CIF |
| Warranty period | 12 months |
| Shipping method | by sea or air; by express |
7) Warranty Policy and Service Program of ESR Series Scale Pallet Truck
SINOLIFT give our customer warranty for each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us that we are always responsible for promotion our service.
Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.
If your products from local distributor, please contact them. We provide full line after-sales service for our distributors. SINOLIFT believe local strategy is the best way for our distributors and local customers.
SINOLIFT offer all of handling equipments are reconditioned to our specifications, which come with a 12 months warranty on major components and 180 days on wearable items
8) Why choose us?
1- We're a material handling company, a pioneer in the industry in China, we've been leading the Chinese warehouse equipment industry since 2001. Sinolift products have been delivered to more than 80 countries.
2- We are unique. We are not assembling, 95% core parts are produced by ourselves. And Sinolift is keeping on investing 30% of its margin on R&D.
3- Strict Quality Control: 48 hours 100% inspection of electronic parts test, 100% Quality Control before delivery, including Noisy, Driving, Lifting, and Welding inspection.
4- Full range products, High-Quality and economic models are both available from Sinolift, we have resources to help our partners to open the market easily.
5- Sinolift has a whole set of failure predication, repair, maintenance data which will reduce 60% of the dealer's after-sale service cost.
