Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > All Aluminium Wire AAC Wire

All Aluminium Wire AAC Wire

Name: All Aluminium Wire AAC Wire
Brand: HNTDDL, HNTDDL
SKU: 132276711

US$ 0.1 - 5 MOQ: 1000 Meters

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

HNTDDL, HNTDDL

Model Number:

10-1500

Contact Supplier Request Quote Chat Now

Henan Tong-Da Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO/SHANGHAI/NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name HNTDDL, HNTDDL

Model Number 10-1500

Type Other, Bare, LV MV HV

Application Other, Overhead, Overhead

Conductor Material Aluminum

Conductor Type Other, Stranded, Solid

Insulation Material Other, bare, No

Product Description

APPLICATION:

AAC used in overhead electric power transmission and distribution lines with various grade voltages. Mainly used in urban areas for electricity transfer where the spacing is short and the supports are closer together. Apart from that, these conductors are also extensively used in coastal area because of their corrosion resistance properties.

CONSTRUCTION:

Aluminum 1350-H19 wires, concentrically stranded.

The most commonly used stranding consists of 7, 19, 37, 61 and 91 wires.

Bare concentric-lay-stranded aluminum wires constructed with a straight round central aluminum wire surrounded by one or more layers of helically laid aluminum wires.
In all constructions, the successive layers shall have opposite directions of lay, the outermost layer being right-handed.

STANDARDS:
IEC 61089, ASTM B231,BS 215 Part 1, EN 50182, DIN 48201 Part 5 etc.

standard

The data sheets below show the standards IEC61089:

Code Number	Nominal area	Stranding&	Approx	Approx	Breaking load	DC Resistance at 20
		Wire	overall	weight
		Diameter	diameter
	mm 2	mm	mm	kg/km	kN	ohm/km
10	10	7/1.35	4.05	27.4	1.95	2.8633
16	16	7/1.71	5.12	43.8	3.04	1.7896
25	25	7/2.13	6.4	68.4	4.5	1.1453
40	40	7/2.70	8.09	109.4	6.8	0.7158
63	63	7/3.39	10.2	172.3	10.39	0.4545
100	100	19/2.59	12.9	274.8	17	0.2877
125	125	19/2.89	14.5	343.8	21.25	0.2302
160	160	19/3.27	16.4	439.8	26.4	0.1798
200	200	19/3.66	18.3	549.7	32	0.1439
250	250	19/4.09	20.5	687.1	40	0.1151
400	400	37/3.71	26	1102	64	0.0721
450	450	37/3.94	27.5	1239.8	72	0.0641
500	500	37/4.15	29	1377.6	80	0.0577
560	560	37/4.39	30.7	1542.9	89.6	0.0515
630	630	61/3.63	32.6	1738.3	100.8	0.0458
710	710	61/3.85	34.6	1959.1	113.6	0.0407
800	800	61/4.09	36.8	2207.4	128	0.0361
900	900	61/4.33	39	2483.3	144	0.0321
1000	1000	61/4.57	41.1	2759.2	160	0.0289
1120	1120	91/3.96	43.5	3093.5	179.2	0.0258
1250	1250	91/4.18	46	3452.6	200	0.0231
1400	1400	91/4.43	48.7	3866.9	224	0.0207
1500	1500	91/4.58	50.4	4143.1	240	0.0193
