AAAC Cable Box Acacia Almond Cedar Deodar

Specifications

The light weight all aluminium alloy conductor has such advantages as high strength, nonexistance of electrochemical corrosion, long service life, sound electricity conductivity, etc. It is used to transmit current and is made through stranding aluminium alloy wires instead of aluminium wires in a spiral manner and according to a certain rule. It's tensile strength is 1.7-1.8 times of that of an ordinary conductor. The rigidity  of our AAAC is very high so the surface scratch when putting up transmission lines can be minimized and the construction quality can be greatly improved.

Standards

AAAC-6201 bare conductor meets or exceeds the following ASTM specifications:

1· B-398 Aluminum-Alloy 6201-T81 Wire for Electrical Purposes.

2· B-399 Concentric-Lay-Stranded 6201-T81 Aluminum Alloy Conductors.

Application

The AAAC is used for overhead power transmission lines , especially the electric power augmentation of old transmission lines. We specialized in the research and application of AAAC for almost ten years. When replacing the aluminium conductor steel reinforced , the AAAC can save 5-8% of the construction cost. This AAAC covers aluminium alloy (hard solution, heat-treated, cold worked, and artifically aged) round wires for electrical purposes to be used as component wires of aluminium alloy conductor and aluminium alloy conductor steel reinforced.

Construction

Standard 6201, 6101 aluminum alloy conductors, are concentric-lay- stranded, similar in construction and appearance to 1350 grade aluminum conductors. They were developed to fill the need for an economical conductor for overhead applications requiring higher strength than that obtainable with 1350 grade aluminum conductors, but without a steel core. The DC resistance at 20°C of the 6201,6101 conductors and of the standard ACSR of the same diameter are approximately the same. Conductors of the 6201,6101 alloys are harder and, therefore, have a greater resistance to abrasion than conductors of 1350-H19 grade aluminum.


Properties:

AAAC has a good corrosion resistance due to being composed out of aluminum alloy wires only, minimum conductivity of 52% IACS,high breaking strength per weight and normal creep values. AAAC has the highest strength per weight among all bare

overhead conductors.

AAAC BS EN 50182:2001

We, Henan Tong-Da Cable Co., Ltd is a professional overhead bare conductor manufacturer, with more than 20 years experience. Our products include:

AAC ( All aluminum conductor)

AAAC (All aluminum alloy conductor )

ACSR (Aluminum conductor steel reinforced)

ACAR (Aluminum conductor aluminum alloy reinforced)

AACSR (Aluminum alloy conductor steel reinforced)

ACSR/AW (Aluminum conductor aluminum clad steel reinforced)

TACSR (Thermal-resistant Aluminum-alloy Conductor, Steel Reinforced)

ACSR/TW (Shaped Wire Compact Concentric-Lay-Stranded Aluminum Conductor, Steel-Reinforced)

ACSS (Concentric-Lay-Stranded Aluminum Conductors, Coated steel Supported)

ACSS/TW (Aluminum Conductors Steel Supported-Trapezoidal)

Aluminium Clad Steel Wire

Galvanized Steel Wire

Copper Stranded Conductors for Electric Railway /Catenary Wire

Trolley Wire for Electric Railway/ Contact wire

ABC Cable

Our main market:

North America
South America
Southeast Asia
Africa
Oceania
Mid East
Central America
Northern Europe
South Asia
