Rigid PCB Capability
Rigid PCB Capability | |||
No. |
Item |
Technical data |
|
1 |
Layer Count |
1-30Layers |
|
2 |
HDI Type |
1+N+1, 2+N+2 |
|
3 |
Material |
CEM3, FR-4, Halogen Free, Aluminum-based, Teflon,Rogers, Getek, Nelco, PTFE, Polyimide etc |
|
4 |
Board thickness |
0.2~5.0mm |
|
5 |
Board Size |
Max. |
600*1000mm (24”x40”) |
Min. |
30x50mm |
||
6 |
Copper Thickness |
Outer layer |
1oz~6oz |
Inner layer |
Hoz~5oz |
||
7 |
Min. Line Width/Space |
4/4mil(0.1/0.1mm) |
|
8 |
Finished Hole size |
Mechanical |
0.20~6.30mm |
Laser |
5mil, 6mil |
||
9 |
Blind/buried via(Mechanical) |
0.2mm (min) |
|
10 |
Aspect Ratio |
10:1 |
|
11 |
Hole Dia.Tolerance |
PTH |
±0.075mm(3mil) |
NPTH |
±0.05mm (2mil) |
||
12 |
Hole Position Tolerance |
±0.05mm (2mil) |
|
13 |
Bow & Twist |
≤0.75% |
|
14 |
Peel strength |
1.4N/mm |
|
15 |
Thermal stress |
288°C & 20 Sec |
|
16 |
Test Voltage |
50-300V |
|
17 |
Soldermask color |
Green, Red, Blue, Black, White |
|
18 |
Silkscreen color |
White, Black, Yellow |
|
19 |
Min. S/M Pitch |
4mil(0.1mm) |
|
20 |
Min. Solder Mask Clearance |
0.05mm |
|
21 |
Impedance Control Tolerance |
+/-10% |
|
22 |
Outline Tolerance |
±0.10mm (4mil) |
|
23 |
Surface Finish |
HASL, Lead free HASL, Immersion Gold/Tin/Silver, OSP, Flash Gold, Gold fingers, Plating Hard Gold, Carbon lnk, Peelable mask |
|
About us
PCB work flow:
Working place:
Certificates :
UL,CE,ISO,lead-free
