Solar Energy Bracket Machine
We do Best, About CHBEST factory
Cangzhou Best Machinery Co,.LTD produce the best quality and international standard color steel forming machine and speical cold roll forming machine.
We Choose the best material and components, and adopting Shanghai’s technology, with 20 year’s experience.
Now the machine working speed can reach 50m/min
Our main products: CZU purlin roll forming machine, deck floor roll forming machine,door series roll forming machine, cable tray roll forming machine, roof and wall roll forming machine, light steel roll forming machine, water channel roll forming machine, glazed tile /ridge cap roll forming machine, highway guardrail roll forming machine, sandwich panel roll forming line, rack and fence roll forming machine and auxiliary equipments.
We do exquisite:
Machine components:
De-coiler------------------------------------------1set
Forming machine--------------------------------1set
Cutting device -----------------------------------1set
Punching device----------------------------------1set
PLC control box --------------------------------1set
Hydraulic pump station-------------------------1set
Production support table-----------------------1set
Technical description:
| No. | Item | Spc. |
| Decoiler | Type | Maunal |
| Inner diameter | 508-600mm | |
| Outer diameter | 1500mm | |
| Max capacity | 5tons | |
| Leveling device | Number of Roller | 5 |
| Function | It is used for making the material flat before feeding into the roll forming machine. | |
| Roll forming machine | Material thickness | 1-3mm |
| Roller stands | 16 stands | |
| Roller material | 45# steel polished and coated with chrome HRC55-60° |
|
| Shaft diameter | 80mm | |
| Shaft material | high grade No.45 steel after treatment |
|
| Trassimission | 1''chain or gear box | |
| Slide plate thickness | 20mm | |
| Main power | 22kw | |
| Speed | 8-12m/min | |
| Votage | 380v,3phase,50HZ | |
| Punching and cutting device | Punching mould material | Cr12Mov, quenching HRC55-60 |
| Cutting mould material | Cr12Mov, quenching HRC55-60 | |
| Type | Hydraulic | |
| Power | 3kw | |
| Control system | Type | PLC Frequency Control System with touch screen |
PLC Brand |
Japan Panasonic |
|
Encoder Brand |
Omron |
|
Length Error |
±2mm | |
| Output table | Function | It is simple and used to load finished product |
| Length | 6m |
We do specialized:
We have professional team to make different kinds of roll forming machines for our customers, from designing, processing, assembling, debugging,delivery.
Guarantee period: 18months free service/ pay service all the machine life
Installation and training:
If buyers visit our factory and check the machine, we will teach you how to install and use themachine, and also train your workers/technician face to face.
Without visiting,we will send you user manual and video to teach you to install and operate.
If buyer needs our technician to go to your local factory,please arrange board and lodging and other necessary things.
We do you like:
1.We are factory ,adopt Shanghai's technology , technical personnel has 20 year's experience,offer best quality machines
2. Customers Design ,Size,Color&Logo are accepted.
3. With20 years professional manufacture experience
4. Prompt Delivery&Competitive Price
5. Main markets:Middle East, Europe, North America, Africa,Southeast Asia.
We do standard:machine loading
We do you care:
WHY CHOOES CHBEST COMPANY
1) Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available across the world. We need your machines running in order to keep your business running.
2)Q: How do your machines compare with other big companies in this market?
A: We are up to date with the latest technology and improve our machines accordingly
3) Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. AOFA is ALIBAB’s Gold supplier with BV assessment and CE certificate.
4)Q:What can you do if the machine broken?
A:Our machine's warranty period is 18months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.
5) Q:Can you be responsible for transport?
A:Yes,please tell me the destination port or address.we have rich experience in transport.
6) Q:Can you supply the raw materials?
A:Yes,we can supply the galvanized steel coil,galvalume steel coil,color steel coil,and aluminum coil.
Hope we could establish win-win business relations in the soon future!
We produce machines according to your different profile drawings:
We do Together, dear Customer, you are CHBEST 's friends. Meeting you, serving all of you, Enjoying with you.
If you arrive at Cangzhou, i can go to Cangzhou west high speed rail station or your hotel to pick you up.
