Cheap Sandwich Panel Roofing Tile Making Machine

Cheap Sandwich Panel Roofing Tile Making Machine photo-1
Cheap Sandwich Panel Roofing Tile Making Machine photo-2
Cheap Sandwich Panel Roofing Tile Making Machine photo-3
Cheap Sandwich Panel Roofing Tile Making Machine photo-4
US$ 4,990 - 9,990 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Forming Machine
Tile Type:
Colored Glaze
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or as customers' request
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Tile Forming Machine
Tile Type Colored Glaze
Use Roof
Production Capacity 10-15m/min
Place of Origin Henan, China
Brand Name HENTO
Model Number HTO-YW1000
Power(W) 4 KW
Voltage 380V
Dimension(L*W*H) 7200mm*1300mm*1500mm
Weight 4 Tons
Certification ISO
Warranty 2 Years
After-sales Service Provided Engineers available to service machinery overseas

Cheap sandwich panel roofing tile making machine



1.Machine introduction:

Glazed tile produced by this kind of  Customized Roofinng Used Coated Surface Treatment Corrugated Glazing Tiles Making Machine are looked beautiful, elegant and noble. It can be widely used in garden-style factory, traveling scenic spots, hotel, exhibition center, villa, civil construction and so on.

   Customized Roofinng Used Coated Surface Treatment Corrugated Glazing Tiles Making Machine consists of feeding platform, main molding core, shearing mechanism, hydraulic station, computer control cabinet, glazed tile roll forming machine, high precision counter and so on.

2.Technical parameters:

Model

HTO-YW1000

Size(mm)

7200mm*1300mm*1500mm

Total weight(kg)

about 4000kg

Material of roller

45#steel,quenched HRC58-62 with polishing

Main motor power

5.0kw;

Hydraulic power

4.0kw

Oil pressure

10Mpa

Thickness of the panel

0.3-1.0mm

Working speed (m/min)

10-15m/min

PLC Type

According with yours demand

(English and Chinese exchange)

Steps of the roller

13 steps

Material of cutting blade

CR12

Feeding width

1000mm





Cheap sandwich panel roofing tile making machineCheap sandwich panel roofing tile making machineCheap sandwich panel roofing tile making machineCheap sandwich panel roofing tile making machine
3.Contact information:

If you need further information, please contact us freely, we will do our best to cooperate with you.

Cheap sandwich panel roofing tile making machine
