24 Port RJ45 Full Gigabit network Fiber Switch with 2 giga SFP port
SW2624GS Gigabit network Fiber Switch supply 24 port GE and 2 giga SFP optical fiber ports,applied to IPC camera, Wireless AP, and IP Phone, and easy for network transmission.
This device comes with SFP port, easy for optical fiber remote transmission.
Main Features
2SFP+24GE, with different modules, can up to 100KM.
500M CPU, 52G bus.
Rack-mount, Computer Room Construction, Dual power supply.
Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3ab.
Fluid Control: Full-duplex: IEEE 802.3x, Half-duplex: back pressure.
Auto MDI/MDIX.
Upstream port lightning protection.
Store-and-forward.
All ports support wire speed switch, jumbo frame transmission.
Zero QFD, self-adaption.
Panel lights can monitor operative mode and malfunction analysis.
Specification
Model |
SW2624GS |
|
Electric Port |
1000M Rj45 |
24 |
SFP |
2 |
|
|
Function |
Exchange Mechanism |
Store-and-forward |
Exchange Capacity |
52G |
|
MAC |
8K |
|
|
Environmental |
Working Temperature:0℃~40℃ Storage temperature :-40℃~70℃ |
|
|
Working Humidity :10%~90% RH non-condensing Storage Humidity:5%~90% RH non-condensing | ||
power |
DC12V 2A AC 110-220V 50/60HZ |
|
|
Network protocol |
IEEE 802.3X IEEE 802.3i 10BASE-T X IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T G IEEE 802.3z 1000BASE-X G IEEE 802.3x Flow control IEEE 802.1q VLAN Bridge operation |
|
|
Default Mode |
Common switch |
|
Match |
VLAN isolation |
|
|
Speed |
Ethernet 10Mbps half-duplex, 20Mbps full-duplex Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex |
|
|
Network Media |
10Base-T: Pair 2 Category 3(cat 3) and above UTP/STP(≤100m) 100Base-TX: Pair 2 Category 5(cat 5) and above UTP/STP(≤100m) 1000Base-T: Pair 4 Category 5 (cat 5e)and above UTP/STP(≤100m) 1000Base-SX:62.5μm/50μm MMF(2m~550m) 1000Base-LX:62.5μm/50μm MM(2m~550m) or 10μm SMF(2m~5000m) |
|
Physical Specifications |
Product Size:285mm*220mm*45mm(L*W*H) package Size:410mm*280mm*95mm(L*W*H) 2kg |
|
Product Ordering Information :
Model Number: SW2624GS
Product Details:2SFP+24GE
