3 Rolls Conveying Coal Heavy Duty Rubber Conveyor Belt

Baoding Milestone Import And Export Trading Co., Ltd.
3 Rolls Conveying Coal Heavy Duty Rubber Conveyor Belt thumbnail-1
3 Rolls Conveying Coal Heavy Duty Rubber Conveyor Belt photo-1
Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Bucket Conveyor
Material:
Rubber
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Bucket Conveyor
Material Rubber
Material Feature Heat Resistant
Structure Belt Conveyor
Load Capacity 1-600t/h
Place of Origin Hebei, China
Brand Name MST
Model Number MSTB/NN
Voltage Custom Design
Power(W) Custom Design
Dimension(L*W*H) Custom Design
Certification ISO9001:2008, ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Nylon Conveyor Belt
1.Carcass:EP,CC,NN
2.Tensile Strength:100~2400N/mm
3.Rubber:Resistant wear,heat,oil
ISO9001:2008

3 rolls conveying coal heavy duty rubber conveyor belt

3 rolls conveying coal heavy duty rubber conveyor belt


Product Description



Conveyor belt are used for bridging medium and long distances and for transporting heavy

material. These standard belts are made of fabric canvas cushioned by layers of rubber and

protected by a wear-resistant cover plate.



Nylon is flexible to adopt a small diameter pulley and is suitable for transporting a variety of

materials like ore, crushed stones, grain, sand, etc., but has a rather weak point in being easily

excessively stretched.





MST® nylon conveyor belt have following advantages:



· Excellent resistance to impact

· Superior in fastener holding ability.

· Unaffected by alkali and weak acids.

· Strong adhesion to rubber.

· Great flexibility and excellent troughability.

· Higher tensile strength compatible with low weight.

· Advanced resistance to mildew, moisture and rotting.





Nylon conveyor belt structure and specification:

3 rolls conveying coal heavy duty rubber conveyor belt



Carcass

Belt width

mm

No. of Plies

Thickness of cover

Top         Bottom

EP100 EP125

300

3~5

4.5 3.0 1.5

3.0 1.5

EP100 EP125

400

3~6

4.5 3.0 1.5

3.0 1.5

EP100 EP125

500

3~6

4.5 3.0 1.5

3.0 1.5

EP100 P125

600

3~6

4.5 3.0 1.5

3.0 1.5

EP100 EP125

650

3~6

4.5 3.0 1.5

3.0 1.5

EP125 EP200

800

3~6

6.0 4.5 3.0 1.5

3.0 1.5

EP150 EP200

1000

3~8

6.0 4.5 3.0 1.5

4.5 3.0 1.5

EP150 EP200

1100

4~10

6.0 4.5 3.0

4.5 3.0 1.5

EP150 EP200

1200

4~10

6.0 4.5 3.0

4.5 3.0 1.5

EP150 EP200

1400

4~10

6.0 4.5 3.0

4.5 3.0

EP200 EP250

1600

5~10

6.0 4.5

4.5 3.0





Cover Rubber Grade

Tensile Strength

Mpa

Elongation at Break

%

Abrasion

mm3

H

24

450

120

D

18

400

100

L

15

350

200



* meet to GB/T 7984-2001standard equal to ISO/FDISI4890-99 standard



We can make all standard:

 3 rolls conveying coal heavy duty rubber conveyor belt




Our Services





Our products:



No.Rubber Conveyor Belt Code
1Sidewall Conveyor Belt MSTB/S
2Conveyor Belt for General PurposeMSTB/P
2.1EP Conveyor Belt MSTB/EP
2.2Nylon Conveyor Belt MSTB/NN
2.3Cotton Conveyor Belt MSTB/CC
2.4Steel Cord Conveyor Belt MSTB/ST
3Conveyor Belt for Specific PurposeMSTB/SP
3.1Heat Resistant Conveyor Belt MSTB/HR
3.2Fire Retardant Conveyor Belt MSTB/FR
3.3Cold Resistant Conveyor Belt MSTB/CR
3.4Oil Resistant Conveyor Belt MSTB/OR
3.5Chemical Resistant Conveyor BeltMSTB/CHR
4Chevron Conveyor Belt MSTB/V
5Elevator Conveyor Belt MSTB/E
6PVC/PU Conveyor BeltMSTPVCB
7V BeltMSTVB



Item

Specification

Unit

Belt width

300-2000

mm

Fabric

NN,CC,EE,EP



Ply

1-10



Belt thickness

6-60

mm

Top rubber cover thickness

1.5-30

mm

Bottom rubber cover thickness

0-30

mm

Tensile strength of 1 ply fabric

100-1000

N/mm

Color

Black



Standard

ISO, RMA, DIN, AS, JIS





3 rolls conveying coal heavy duty rubber conveyor belt



Production Processing:







Packaging & Shipping

Packing & Shipping:

3 rolls conveying coal heavy duty rubber conveyor belt






Company Information



 3 rolls conveying coal heavy duty rubber conveyor belt



 3 rolls conveying coal heavy duty rubber conveyor belt

FAQ



Inquiry List

Belt width



mm

Fabric



Ply



mm

Top and bottom rubber thickness



Mpa

Tensile strength of cover rubber



m

Belt length



Transport material



Material size



mm

Material temperature



Degree
