Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt

Baoding Milestone Import And Export Trading Co., Ltd.
Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt thumbnail-1
Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt photo-1
Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Slat Conveyor
Material:
Rubber
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Ang Port in China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Slat Conveyor
Material Rubber
Material Feature Heat Resistant
Structure Belt Conveyor
Load Capacity 1-600t/h
Place of Origin Hebei, China
Brand Name MST
Model Number MSTB/EP
Voltage Custom Design
Power(W) Custom Design
Dimension(L*W*H) Custom Design
Certification ISO9001:2008, ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Rubber Conveyor Belt
1.Carcass:EP,CC,NN
2.Tensile Strength:100~2400N/mm
3.Rubber:Resistant wear,heat,oil

Rubber Conveyor Belt

Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt


Product Description

EP conveyor belt with are robust and are suitable for heavy duty operations due to their

polyester/polyamide ply design. The low elongation tension member enables short take ups.

The belt gives high resistance to penetration damage and optimum adhesion between plies.

MST EP with cut edges or rubber edges is resistant to rotting; it is easy to mould and guarantees

high operational reliability and durability, even with small pulley diameters. The use of modern

textiles and state of the art production technologies ensures that MST EP retains its belt alignment

 over a long service life.



Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt







MST® EP conveyor belt are primarily used in the following industries:

· Chemical industry

· Coal-fired power stations

· Iron and steel industry

· Quarries

· Recycling industry

· Sand and gravel industry





EP conveyor belt structure and specification:



Carcass

Belt width

mm

No. of Plies

Thickness of cover

Top         Bottom

EP100 EP125

300

3~5

4.5 3.0 1.5

3.0 1.5

EP100 EP125

400

3~6

4.5 3.0 1.5

3.0 1.5

EP100 EP125

500

3~6

4.5 3.0 1.5

3.0 1.5

EP100 P125

600

3~6

4.5 3.0 1.5

3.0 1.5

EP100 EP125

650

3~6

4.5 3.0 1.5

3.0 1.5

EP125 EP200

800

3~6

6.0 4.5 3.0 1.5

3.0 1.5

EP150 EP200

1000

3~8

6.0 4.5 3.0 1.5

4.5 3.0 1.5

EP150 EP200

1100

4~10

6.0 4.5 3.0

4.5 3.0 1.5

EP150 EP200

1200

4~10

6.0 4.5 3.0

4.5 3.0 1.5

EP150 EP200

1400

4~10

6.0 4.5 3.0

4.5 3.0

EP200 EP250

1600

5~10

6.0 4.5

4.5 3.0





Item

Specification

Unit

Belt width

300-2000

mm

Fabric

NN,CC,EE,EP



Ply

1-10



Belt thickness

6-60

mm

Top rubber cover thickness

1.5-30

mm

Bottom rubber cover thickness

0-30

mm

Tensile strength of 1 ply fabric

100-1000

N/mm

Color

Black



Standard

ISO, RMA, DIN, AS, JIS











We can make all standard:



Cover Rubber Grade

Tensile Strength

Mpa

Elongation at Break

%

Abrasion

mm3

H

24

450

120

D

18

400

100

L

15

350

200



* meet to GB/T 7984-2001standard equal to ISO/FDISI4890-99 standard





Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt




Our Services





Our products:



No.Rubber Conveyor BeltCode
1Sidewall   Conveyor BeltMSTB/S
2Conveyor   Belt for General PurposeMSTB/P
2.1EP   Conveyor BeltMSTB/EP
2.2Nylon   Conveyor BeltMSTB/NN
2.3Cotton   Conveyor BeltMSTB/CC
2.4Steel   Cord Conveyor BeltMSTB/ST
3Conveyor   Belt for Specific Purpose:MSTB/SP
3.1Heat   Resistant Conveyor BeltMSTB/HR
3.2Fire   Retardant Conveyor BeltMSTB/FR
3.3Cold   Resistant Conveyor BeltMSTB/CR
3.4Oil   Resistant Conveyor BeltMSTB/OR
3.5Chemical   Resistant Conveyor BeltMSTB/CHR
4Chevron   Conveyor BeltMSTB/V
5Elevator   Conveyor BeltMSTB/E
6PVC/PU Conveyor BeltMSTPVCB
7V BeltMSTVB







Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt





Production Processing:






Packaging & Shipping

Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt








Company Information



 Long Distance Wide Stone Hauling Stone Rubber Conveyor Belt




FAQ





Inquiry List

Belt width



mm

Fabric



Ply



mm

Top and bottom rubber thickness



Mpa

Tensile strength of cover rubber



m

Belt length



Transport material



Material size



mm

Material temperature



Degree
