Solar power inverter 150W off grid pure sine wave inverter. 12V/24V48VDC to 100/110/120/220/230/240V AC
- 1000 Piece / Pieces per Month
- SHENHEN/SHANGHAI/NINGBO
- T/T Credit Card PayPal
- electric ac motor speed controller 480V 32A 18kw 3phase Input&3Phase Output AC frequency converter with 18 months warranty
- 45kw 380v vector control ac frequency converter 50hz 60hz motor frequency inverter 3 phase Power Frequency Converter for Pump
- EM15-G3 General used Vector control Frequency inverter(3 phase )
- EMHEATER soft starter
- EM GS2 7.5KW 220V 240V Motor Soft Starter for Submersible Pump deep well
- Inverter AB PowerFlex®7 Converter 22CD012N103 Inverter PowerFlex 400- 5.5 kW (7.5 HP) AC Drive
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | R&X | Model Number: | RX-150-S |
Output Power: | 101 - 200W | Output Type: | Single | Size: | 180mm*105mm*60mm |
Weight: | 1kg | Input Voltage: | DC12V/24V | Output Voltage: | AC100-120V AC220-240V |
Type: | DC/AC Inverters | Output Frequency: | 50Hz/60Hz |
Product Description
Specifications
solar power inverter1.Input:12V/24V48VDC
2.Output:100/110/120/220/230/240V AC
3.Pure sine wave
Solar power inverter 150W off grid pure sine wave inverter. 12V/24V48VDC to 100/110/120/220/230/240V AC
Sample Purchase online: Click here
Technical Data
Model | RX-150-S | |
Input | DC Voltage | 12V,24V,48V |
Voltage Range | 10-15VDC or 21-30VDC or 42-60VDC or 92-132VDC | |
No Load Current Draw | <0.5 | |
Efficiency | > 85% | |
DC Connector | Cables With Clips or Car Adaptor | |
Output | AC Voltage | 100/110/120VAC or 220/230/240 VAC |
Continuous Power | 150W | |
Surge Power | 300W | |
Waveform | Pure Sine Wave | |
Frequency | 50Hz or 60Hz | |
AC Regulation | 3% | |
Protection | Low Voltage Alarm | 10DC+/-0.5V or 20.5DC+/-1V or 44VDC+/-1V or 100VDC+/-1V |
Low Voltage Shut Down | 9.5DC+/-0.5V or 19.5DC+/-1V or 42VDC+/-1V or 96VDC+/-5V | |
Over Load | Shut Off Output | |
Over Voltage Shut Down | 15.5V or 30.5V or 61.2V or 120V | |
Over Thermal | Shut Off Output Automatically | |
Fuses | Short Circuit | |
Environment | Working Temperature | Between -10 and +50 |
Working Humidity | 20%-90%RH non-condensing | |
Storage Temperature | Between -30 and +70 | |
Package | Machine Size(mm) | 180X105X60 |
Packing Size(mm) | 245X122X75 | |
Net Weight(kg) | 0.86 | |
Gross Weight(kg) | 1.0 | |
Packing Mode | Carton | |
Other | Start | Soft Start |
Cooling Ways | Intelligent Cooling Fan |
Description
1. This power inverter instantly convert low voltage DC power to high voltage AC household power.
2. High reliability and low failure rate by using the advanced Double-CPU single chip intellectual
control technology.
3. Pure sine wave output. Small, light and artistic, benefited from adopting the SMD pastern
technology.
4. Cooling fan is intellectual controlled, and its working status is controlled by CPU, which
mostly increased its service life and helps to save the power consumption, improve work
efficiency and lower the working noise.
5. You can use many places. Such as Solar electric energy generation, Wind power generation,
Communication equipment, Industrial intellectual control system, Small sized emergency power
supply system
Socket design for different countries
