12HP, DF-12 & DF-12L Walking Tractor With Rotary Cultivator

12HP, DF-12 & DF-12L Walking Tractor With Rotary Cultivator thumbnail-1
12HP, DF-12 & DF-12L Walking Tractor With Rotary Cultivator photo-1
Negotiable MOQ: 2 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Walking Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Yancheng Dayang Farm Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Walking Tractor
By wheel 2WD
Usage Farm Tractor
Certificate Other
Brand Name Huiyou
Model Number DF-12/12L
Place of Origin Jiangsu, China

Specifications

1.Simple and compact construction tractor
2.Efficient output
3.Multifunctional
4.Competitive price
5.Attentive service

1.Instruction of the walking tractor

     The Tractor is featured by its simple and compact construction , reliability , long service life ,easy operation , ample output , light weight and high versatility This tractor is very suitable for use in paddy field , small dry field , orchards , vegetable gardens of hilly land with small inclination . It can be used for ploughing , rotary cultivating , harrowing in paddy field , harvesting , transportation ,etc .if suitable implements or accessories are attached . In addition , the tractor can be extensively used as a stationary power station for small scale drainage and irrigation , spraying , grain threshing , cottons ginning , flour milling , fodder cutting , etc.

2.Main specifications

Model

            DF-12

DF-12L

Diesel engine

ZS/S 195

ZS/S 195NL

Type

1-cylinder, 4stroke, horizontal, hopper water cooled diesel

1-cylinder, 4stroke, horizontal, hopper water by diesel condenser

Rated power (kW/hp)

8.82 / 12

Rated speed (rpm)

2000

Cooled system

Evaporative

Radiator

Overall dimension
(LXWXH)  (mm)

2680x 960x1250

Wheel tread (mm)

800, 740 , 640 , 580

Tyre

6.00 - 12

Ground clearance (mm)

182

Clutch type

Two-disc, constant-contact, friction

Construction  weight (kg)

350

Forward (km/hr)

1.40     2.50   4.10   5.30   9.40  15.30

Reverse (km/hr)

1.10     3.80

Optional implement

1. 1LS-220C Two share plough     9. 1LYQ-320 Three disc plough

2. 1LS-220Y Two disc plough       10.1LYQ-420 Four disc plough

3. 7C-1.5 Trailer                  11. 2BG-5A Rotary seed drill

4. 65BP-55 Water pump           12. 2BG-6A Rotary seed drill

5. 4GL-120 Reaper                 13. 100-640 Anti-skid iron wheel

6. 4GL-150 Reaper

7. 1KS-30 Ditching machine

8. PY series Sprinkler
