8 HP Small Farm Tractor(JM-81& JM-81L)

Specifications

Features of farm tractor:
1. simple and compact constraction
2. ample output
3. high versatility
4. long service life

1.Instruction of the farm tractor:

The farm tractor is featured by its simple and compact construction , reliability , long service life ,easy operation , ample output , light weight and high versatility This tractor is very suitable for use in paddy field , small dry field , orchards , vegetable gardens of hilly land with small inclination . It can be used for ploughing , rotary cultivating , harrowing in paddy field , harvesting , transportation ,etc .if suitable implements or accessories are attached . In addition , the tractor can be extensively used as a stationary power station for small scale drainage adn irrigation , spraying , grain threshing , cottons ginning , flour milling , fodder cutting , etc.



2.Main specification:

Model	JM-81	JM-81L
Diesel engine	R185	R185NL
Type	1-cylinder, 4stroke, horizontal, hopper water cooled diesel	1-cylinder, 4stroke, horizontal, hopper water by diesel condenser
Rated power (kW/hp)	5.88 / 8
Rated speed (rpm)	2600
Cooled system	Evaporative	Radiator
Overall dimension  (LXWXH)  (mm)	2180x 890x1250
Wheel tread (mm)	650, 730
Tyre	6.00 - 12
Ground clearance (mm)	234
Clutch type	Two-disc, constant-contact, friction
Construction  weight (kg)	155
Forward (km/hr)	2.31     3.82   6.11   7.77   12.83  20.51
Reverse (km/hr)	3.77     12.66
Optional implement	1. 1LS-120 One share plough 2. 1LGK-125 Once share plough 3. 7C-1.0 Trailer 4. 65BP-40 Water pump 5. 4GL-100 Reaper 6. PY series Sprinkler About the detail of implement , please visit our website:
