1.8M/3.2M Double Sided Printer 77802/ 77802L, Inkjet Printer
Comparison with Single Side
Briefing: 3.2m print width with two DX7 print heads.
Working method:
1. Print on front side.
2. Reverse media
a. If several pieces image,Reverse the media by hand after front side print out, print on backside.
b. If whole roll of media,The take up system and feed system can be replaced easily.
1) Print sequence is Last to First
2) File name is print out in front side, when print back side, select the file generated by software will be ok
c. The back side’s image can be printed by lower pass.Saving time while the result is almost same.
Attention:
For 1.8M, the media size we accept is “152cm, 180cm”
For 3.2M, the media size we accept is “152cm, 180cm, 220cm, 320cm”
Let us know if need special width setting.
Link: /watch?v=a9OzSHhZ6cY&list=PL3nfrqB1qbF
GBeRnZ991n5KrAm7byCDoX
Details of A-Starjet Double Side Inkjet Printer :
Tension Take-up System
Bulk Ink System
Feed System
Camera
Specifications
| Item | A-Starjet 77802L | A-Starjet 77802 | |||
| Print Head | Two DX7 Drop-on-demand Micro-Piezo Print Heads | ||||
| Number of Nozzles | 2880 nozzels(2 heads) | ||||
| Color | 4 Colors:CMYK | ||||
| Resolution | 1440Dpi(Max) | ||||
| Height of Head | 2-5mm | ||||
| Size of Ink Droplet | 1.5-21pl | ||||
| Printing Width | 3200mm | 1800mm | |||
| Media Width | 3300mm | 1900mm | |||
| Real Time Tracking | 4 cameras | 3 cameras | |||
| Print Speed | 2 pass:52 sqm/hour/side | 2 pass: 49 sqm/hour/side | |||
| 4 pass: 28 sqm/hour/side | 4 pass: 25 sqm/hour/side | ||||
| Media Feeder | Detachable Caster | Yes | |||
| Media Take-up | Feeder/Take-up system | Yes | |||
| Payload | 200kgs | 70kgs | |||
| Heating System | 3-section heaters with PID temperature control | ||||
| Ink | T5.5 eco-solvent ink | ||||
| Ink Cartridge | 8 cartridges | ||||
| RIP Software | Iprint 3.0 (Optional Photoprint, Wasatch) | ||||
| Control Software | iPrint console | ||||
| PC System | Win XP & Win 7 | ||||
| Power Voltage | AC220-24V 50-60Hz or AC110-120V 50-60Hz | ||||
| Environment | Temperature:20-26℃ ,Humidity:40-60% | ||||
| Printer Dimension | W4300× D900× H1250mm | W2840× D900× H1250mm | |||
| Packing Dimension | W4450× D1450× H1180mm | W2920× D930× H730mm | |||
| Gross Weight | 795Kgs | 380Kgs | |||
1.Media they all have tension, especial with ink, heating and soon. The seven calibration point on Iprint Console for pre-correction of different media ensure the ultimate fine tune in your very print jobs.
Advanced auto calibration system, it makes 1) print entire roll double side image
2) different image on both sides( hanging scroll)
3) simple and efficient
4) low passes can print at back side
2. Vivid color
It's more and more hard to get people's attraction in the sea of advertising signs. An ultimate weapon to provide the best print quality on indoor/ outdoor backlit sign making, without limitation on size, color and resolution, the last obstacle need to breakthrough to win people's attraction will be art designers' imagination.
A-Starjet 77802L inkjet printer can print vivid color in photo quality without size limitation on post-production by using relatively low cost flex banner to replace backlit film.
3. The replaceable media handle system makes double sided printing more convenient.
To make profits, the 77802L double side inkjet printer not only offers work of art, but also outputs with high efficiency and productivity. The detachable media handle system makes double side printing much easier to operate. Additional pole can be selected for efficiency. Unique tech. supports different pass printing for back side offers more flexibility.
4. Mechanical precision is a critical part for double sided printing. We have done far more than just rely on that, a unique intelligent realtime tracking and correction system has been brought in to ensure the precision. A system which provides almost hand-free operation and even correct manmade error.
- All parts directly contact with ink are not guaranteed except use A-Starjet's ink
- 5 months guaranteed for DC motor
- 15 months for all Boards
- Counting from the day that printer leaves factory
- Within Guarantee time, factory covers freight for sending parts
- Working time: Monday to Saturday--8:30 a.m. to 11:30a.m. , 12:30 p.m. to 17:30 p.m. Personally, every day's 20:00 p.m. to 22:30 p.m. is also my working time.
As a R&D manufacturer, we create a completely new technology to achieve the ultimate double sided printing. The chance to everyone in printing industry is equal, what makes different is that only minority is willing to take it.
In May 2009, we successfully launched the A-starjet series printers, the high-precision indoor&outdoor printers, making great influence in the market. The machine is mainly used in the fields of indoor&outdoor advertising, labels and signs, textile printing, decoration, gifts, wedding photos, and so on. Based on customer particular requests, we can provide the overall resolution packages refer to machine/software design, printing technique, ink development etc.
