NEW HOT Ore mining machinery RJ series single impeller agitating tank

Name: NEW HOT Ore mining machinery RJ series single impeller agitating tank
Brand: Zhaoxin
Availability: InStock

FOB Price

US$ 1,000 - 50,000 / Set

1 Set(Min. Order)

Port Qingdao/Shanghai/Shenzhen
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	Zhaoxin
Model Number	RJ25	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Packaging Details

Standard packaging or as per customer's requests

Product Description

Features of agitator tank

1.1 Product Features

This product is the most commonly used ordinary agitating tank at present. The impeller is located at the bottom opening of the cycling cylinder, taking the ore pulp and chemical reagent into the cycling cylinder with a suction orifice for agitating. The new impeller designed through experiments is different from the original agitating tank I and II, with high agitating efficiency.

1.2 Notes for selection

1.2.1 We can make rubber and nylon etc. impeller as required by the customer. Please specify the type while placing your order.

1.2.2 We can arrange the relative positions of motor, feeding opening and discharging opening as required by the customer. Generally, relevant parts are assembled at the time of on-site installation.

1.2.3 There are two types of RJ agitating tank: cone base and flat base. Please specify it if a cone base type is demanded.

Technical parameter of agitator tank

Standard Model	Internal Size of trough		Effective Volume m3	Stirrer		Motor		Dimension		Weight
	Diameter	Height		Dia-	Speed	Model	Power	Height(mm	Length	(kg)
	(mm)	mm		meter	(r/min)		(KW)		mm
				(mm)
RJ05	500	500	0.078	150	690	Y802-4	0.75	874	720	110
RJ07	750	750	0.26	240	530	Y90L-4	1.5	1241	939	228
RJ10	1000	1000	0.58	240	530	Y90L-4	1.5	1665	1300	350
RJ12	1200	1200	1.14	400	320	Y132S-6	3	1858	1540	765
RJ15	1500	1500	2.2	400	320	Y132S-6	3	2386	1690	1360
RJ20	2000	2000	5.5	550	230	Y132M2-6	5.5	3046	2381	1655
RJ25	2500	2500	11	625	230	Y160M-6	7.5	3546	2881	2766
RJ30	3000	3000	19.1	900	210	Y225S-8	18.5	4325	3266	4296
