Super Glue Laminating Machine

Name: Super Glue Laminating Machine
Brand: EOMAE
SKU: 131675173
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Medical, Chemical, Textiles

Packaging Type:

Case

Yancheng Xinzhan Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Medical, Chemical, Textiles

Packaging Type Case

Packaging Material Wood

Automatic Grade Semi-Automatic

Driven Type Electric

Voltage Customizable

Power 46 KW

Place of Origin Jiangsu, China

Brand Name EOMAE

Model Number LN-Super Glue Laminating Machine

Dimension(L*W*H) 9200 x 2700 x 2500 mm

Weight 3800 KGS

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

* Super glue
* Both roll and sheet materials
* Easy to operate
* Superb processing
* Thoughtful after-sales service

LN - Super Glue Laminating Machine

Applications

Used for gluing material and laminating with other materials, suitable for laminating insole, pad, EVA, PVC, foam, sponge, carpet, plastic, leather, synthetic leather...
Applicable to both roll and sheet materials;
Widely used in shoemaking, luggage, Packaging, interior decoration, car interiors, toy and other industries.

Key Features

Equipped with high quality conveyor belt, applicable to both roll and sheet materials, and helps to improve the smoothness of the products, make the products bonded more firmly;
Equipped with high quality heat resistance net belt to make the laminated materials contact closely with the drying cylinder, to improve the drying effect, and make the laminated product soft, washable, and strengthen adhesive fastness;
Equipped with two sets of heating system, user can select one set heating mode or two sets, to reduce the energy consumption and lower costs;
Surface of the drying cylinder is coated with Teflon to avoid glue;
Pneumatically controlled or handwheel controlled clamp roller;
Equipped with automatic infrared centering control unit, which can effectively prevent the net belt deviation, and ensure the net belt service life;
Efficient cooling unit is suitable for various materials;
Low maintenance cost and simple to maintain.

Options

Main Technical Data

Model:	LN-Super Glue
Working Width:	1800 mm
Drying Cylinder Diameter:	1500 mm
Drying Cylinder Width:	2000 mm
Heating Tube Inside Drying Cylinder:	30 PCS x 1.5 KW
Running speed:	1-40 m/min
Power:	46.0 KW
Net Weight:	3800 KGS
Dimension:	9200 x 2700 x 2500 mm
