Home > Packaging & Printing > Packing Machinery > Laminating Machine > Hotmelt Powder Laminating Machine LP-1800

Hotmelt Powder Laminating Machine LP-1800

Hotmelt Powder Laminating Machine LP-1800 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Medical, Chemical, Apparel, Textiles
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Medical, Chemical, Apparel, Textiles
Packaging Type Case
Packaging Material Wood
Automatic Grade Semi-Automatic
Driven Type Electric
Voltage Customizable
Power 48.0 KW
Place of Origin Jiangsu, China
Brand Name EOMAE
Model Number LP-1800
Dimension(L*W*H) 12800 x 2300 x 1850mm
Weight 5000 KGS
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

* Hot melt powder
* Bamboo charcoal powder
* Energy-saving baking oven
* Thoughtful after-sales service





LP-1800 Hotmelt Powder Laminating Machine





Applications:

  • Used for transferring Hot melt powder or Bamboo charcoal powder onto fabric or other material, after heating, then laminate it with other materials, suitable for laminating fabric, nonwoven, sponge...
  • Widely used in garments, shoes, car interiors, decoration, and other industries.





Key Features:

  • Applicable to hot melt powder, bamboo charcoal powder;
  • Professionally designed powdering unit, is equipped with stirring, vibrating system. Powder is transferred onto material surface very evenly and stably, easy to control powdering amount, and it can also help to reduce powder loss;
  • Energy-saving baking oven, with good heat-insulation performance, can minimize heat loss;
  • Baking oven is equipped with high quality temperature control system, to ensure a constant oven temperature, very small temperature difference. Temperature is controlled through an adjustable temperature controller. User may adjust the baking oven temperature according to different materials to achieve best laminating effect.
  • Running speed is controlled through frequency synchronization, synchronic speed adjusting, very easy and convenient to operate;
  • Both unwinding and winding have magnetic constant tension control;
  • Automatic hydraulic centering unit ensures edge alignment in laminating;
  • Equipped with pneumatic expanding shaft for easy operation;
  • Efficient cooling unit;
  • Edge cutting unit;
  • Counting unit.





Options:

  • Machine working width
  • Servo motor
  • Machine color





Main Technical Data



Model:   LP-1800
Working Width:   1600 mm
Roll Width:   1800 mm
Running Speed:   0~15 m/min
Powdering Amount:   20~500 g/m2
Baking Oven Length:   6000 mm
Heating Mode:   Electric
Power:   48.0 KW
Net Weight:   5000 KGS
Dimension:   12800 x 2300 x 1850 mm





Machine Photo



Hotmelt Powder Laminating Machine LP-1800





* If more details or any assistance wanted, feel free to contact us.
