Auto Feeding PVC Die Cutting Machine

Name: Auto Feeding PVC Die Cutting Machine
Brand: EOMAE
SKU: 131673647

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Hydraulic Cutting Machine

Application:

Plastic, Rubber, Leather, Paper board ...

Yancheng Xinzhan Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Hydraulic Cutting Machine

Application Plastic, Rubber, Leather, Paper board ...

Place of Origin Jiangsu, China

Brand Name EOMAE

Model Number C4A-40T

Rated Power 4.5 KW

Dimensions 2300 x 2110 x 1500 mm

Voltage Customizable

Power(W) 4.5 KW

Certification ISO CE

After-sales Service Provided Engineers available to service machinery overseas

C4A-40T Auto Feeding PVC Die Cutting Machine

Application

Mainly used for die cutting PVC, leather and leather products, plastic, rubber, sponge, foam, EVA, cardboard, paper products, fabric, home textiles, packaging materials, non woven, carpet, car cushion, felt, synthetic materials, and other non-metallic materials in various industries;
Extremely suitable for cutting multiple layers of material at one time;
C4A Series cutting machines are models that equip Automatic Feeding Table on the basis of C4 Series cutting machines.

Key Features

Machine body is made of high quality steel, very strong and durable;
Benefiting from the integrated design of mechanics, electrics and hydraulics, it's very easy to operate, no complicated operating training is required (anyway, the operators shall know operating rules and process, and illegal operating is strictly prohibited);
Hydraulic drive mode, all hydraulic system components are of superb quality;
Precise 4 column machine structure, and double connecting bar make the machine run extremely balanced and stable, keep the same cutting depth in the whole cutting area;
Automatic lubrication system, the machine is lubricated automatically during operation. This design can reduce abrasion;
Double oil cylinders, and automatic oiling during operation;
Automatic Feeding Table is equipped, the materials can be fed for cutting automatically, so it will greatly reduce the workload, and inprove working efficiency;
Two-handed operation design and emergency stop device can ensure safe operation;
Easy and convenient to install cutting mold, so is the machine's setting and adjusting;
Low maintenance cost;
Low running noise.

Options

Main Technical Data

Model:	C4A-40T
Cutting Force:	40 Ton
Platen Size:	1600 x 610 mm
Bed Size:	1600 x 610 mm
Cutting Stroke:	0-145 mm
Distance between Platen to Bed:	45-190 mm
Motor:	3.0 KW / 6 Pole
Hydraulic Oil:	110 Liters of 46 anti-wear hydraulic oil
Net Weight:	2400 KGS
Dimension:	2300 x 710 x 1500 mm

Auto Feeding Table
Frequency Converter:	MITSUBISHI
Auto Feeding Motor:	1.5 KW
Auto Feeding Table Actual Dimension:	1600 x 1250 mm
Auto Feeding Table External Dimension:	1700 x 1400 mm
Weight:	260 KGS
