Cardboard Cutting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Commodity, Textiles
Packaging Type:
Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Apparel, Commodity, Textiles
Packaging Type
Case
Packaging Material
Wood
Automatic Grade
Semi-Automatic
Driven Type
Hydraulic
Voltage
Customizable
Power
2.2 KW
Place of Origin
Jiangsu, China
Brand Name
EOMAE
Model Number
C4S-30T
Weight
1800 KGS
Dimension(L*W*H)
2250 x 750 x 1500 mm
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
C4S-30T Cardboard Cutting Machine
Application
- Mainly used for die cutting leather and leather products, plastic, rubber, sponge, foam, EVA, PVC, cardboard, paper products, fabric, home textiles, packaging materials, non woven, carpet, car cushion, felt, synthetic materials, and other non-metallic materials in various industries;
- Economical cutting solution.
Key Features
- Machine body is made of high quality steel, very strong and durable;
- Hydraulic drive mode, all hydraulic system components are of superb quality;
- 4 column structure and double connecting bar make the machine run very balanced and stable;
- Semi-automatic lubrication system can reduce abrasion;
- Double oil cylinders, and automatic oiling during operation;
- Two-handed operation design and emergency stop device can ensure safe operation;
- Easy and convenient to install cutting mold, so is the machine's setting and adjusting;
- Low maintenance cost;
- Low running noise;
- Advanced technology, qualified parts and superb workmanship will ensure the machine's running stability and service life.
Options
- Automatic feeding system, applicable for roll material or sheet
- Fine motion unit on cutting bed
- Pneumatic clamp unit for die cutter / knife mold
- Platen Size / Bed Size
- Machine color
Main Technical Data
| Model: | C4S-30T |
| Cutting Force: | 30 Ton |
| Platen Size: | 1600 x 620 mm |
| Bed Size: | 1600 x 650 mm |
| Cutting Stroke: | 0-145 mm |
| Distance between Platen to Bed: | 45-190 mm |
| Motor: | 2.2 KW / 6 Pole |
| Hydraulic Oil: | 90 Liters of 46 anti-wear hydraulic oil |
| Net Weight: | 1800 KGS |
| Dimension: | 2250 x 750 x 1500 mm |
Machine Photos
Mold Samples
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2011
Factory Size
3,000-5,000 square meters
Total Employees
101 - 200 People
