1920x1200 lcd screen 10.1inch with MIPI interface for tablet pc notebook
- HK/Taiwan/Shanghai
- Credit Card
You May Like
-
WXGA16:10 ratio , 1280(H)x800(V) screen and 16.7M colors, 10.1inch panel
-
HDMI, VGA,AV interface Driver board for industrial, lcd controller board DM37F
-
10.1 tablet lcd panel with mipi interface
-
10.1 inch lcd panel with mipi interface for note book, IPS lcd panel
-
tft lcd display universal lcd controller board with VGA, DVI interface
-
TFT type HDMI lcd control board
Product Details
Place of Origin | Jiangsu, China | Brand Name | LEEHON | |
Model Number | LH101MP19201200-WUXGAVVX | Type | TFT |
Product Description
1920x1200 lcd screen 10.1inch with MIPI interface for tablet pc notebook :
Cheap price;
Offer 12 months of warranty;
high resolution(1920*1200)
MIPI Interface
LED Backlight Design, Slim Design,LED Driver Combined
Longevity Support
Industrial grade 10.1 inch tft lcd (LH101MP19201200-WUXGAVVX) data sheet | |
Module number | LH101MP19201200-WUXGAVVX |
Resolution | 1920 x 1200 |
Pixel Pitch | 0.11325 X 0.11325 (mm) |
Active Area | 217.44(H) x 135.9(V) (mm) |
View angle | R/L/U/D 89/89/89/89(Deg) |
Mode | AHVA |
LCD Surface | glare,2H |
Number of Colors | 16.7M ( RGB 6-bit + FRC) |
Electrical Interface | MIPI 4Lans |
Brightness | 450 cd/m2 |
Contrast ratio | 1000:1 |
Outline dimension | 228.96(H)x148.5(V)x4.133 (D)(mm) |
Gross weight | 136g(Typ.) |
Backlight | WLED |
LED Life (hrs.) | 50K(Min.) |
Power Consumption (W) | (Typ.) |
Supply Voltage (V) | 0-5.0 V |
Response time | 25 (ms) |
Operate temperature | 0-50 (°C) |
Storage temperature | -20~+60 (°C) |
Package | Standard carton |
According to customers' various requests,tft lcd, lcd panel, lcd monitor, lcd screen, lcd display, industrial lcd, we can match all accessories which inclusive of driver board, touch-screen, LED backlight & LVDS cables.
Quality promised, 100% original,fast delivery,also enjoy one year guarantee !
For further information please contact
Celia Jiang
skype: leehon808
Tel: +86-571-86684288
For you to know more about Hangzhou LEEHON:
Main brand:
* Leehon is one of the main agents for AUO/Tianma/Innolux/Mitsubishi/CMI five brands tft lcd moulds in China from 2009, so from here you can get the most competitive price for real products;
Range of size:
* Leehon can provide the lcd from 2.2 inch to 24 inch with stable supplied;
Quality control system:
* All the panels are 100% original and brand new, no fake panels exists, quality promised; And also Provided 12 months of warranty, you can return any fake panels and charges by us, so from here you can enjoy the real panels directly from original factory;
* Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check then;
The most competive price for real products:
* Here will send the products from the original factory directly to control the price and quality.
* We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from here you can get more convenient delivery;
Our parters:
* Products are sold to more than 20 countries, regular supplier of Marvell(USA), EUROCOMPOSANT(Franch), Jabert Italia srl(Italy), Russian Federation(OOO West-Ost ) etc., so from here you can get more stable supplying promise; to be continue......
After-Sale service:
*Leehon will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;
To choose the best TFT LCD solution:
*Pls choose your interested tft lcd with model number,size, resolution, brightness, operating temperature or life time in our alibaba website http://cnhzlh.en.china.cn,
*More products' info, pls welcome to visit our website
*Our staff holds an unwavering commitment to quality with a sharp focus on delivering tangible results no matter the project. Whether you are a global superbrand or an exciting young company on the rise, we'll partner with you to build valuable relationships.
