1050mA one channel DC12-48V 0/1-10V led dimming driver
Feature :
0 - 10V to PWM dimming signal conversion.
Optical isolation protection for input & output.
Compatible with many brand dimming systems.
Working voltage from DC12V~DC48V
Single output channel, Constant current 1050mA
Multi units can be worked together or use our power repeaters to control more lamps.
- power loss momery function
Specification :
| Name | Value |
| Brand | Bincolor |
| Model | BC-330-1050 |
| Production Capacity | 5000Piece/Pieces per Month |
| Input voltage | DC12V-DC48V |
Max Current Load |
1050mA |
| Driving LEDs |
12V 1~3 PCS 5W LED 24V 1~6 PCS 5W LED 36V 1~9 PCS 5W LED 48V 1~12 PCS 5W LED |
Input Signal |
0-10V analog dimming signal |
Output Signal |
Constant Current PWM |
| Certification | CE ,FCC ROSH |
| Dimension(L*W*H) | L125×W45×H36(mm) |
| Weight | 100g |
Package Dimension |
L131×W49×H49(mm) |
Dimensions:
Conjunction Diagram
0/1-10V input connection:
Amplifier connect in parallel:
Amplifier connect in series:
