14000 Gs wet high-intensity magnetic separator

Name: 14000 Gs wet high-intensity magnetic separator
Brand: HUATE
Availability: InStock

FOB Price

USD $20,000 - $530,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port any port in China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Magnetic Separator
Production Capacity	As you required	Place of Origin	Shandong, China
Brand Name	HUATE	Model Number	kinds of models
Voltage	As you required	Power(W)	As you required
Dimension(LWH)	As you required	Weight	2~175 tons
Certification	ISO/CE	Warranty	one year
After-sales Service Provided	Overseas service center available

Product Description

LHGC vertical ring 14000 Gs wet high-intensity magnetic separator

1.Global Third -generation Vertical Ring High Gradient Magnetic Separator(Forced Oil Cooling Circulation)

Advantages:

With advance structure, easy maintenance and reliable operation, good performance, wide applicability to ore granularity, ore density and ore grade which realize the goal of good concentration and good reclamation.

2.Global Fourth-generation Vertical Ring High Gradient Magnetic Separator(Oil-water Complound-cooling)

Application:

LHGC vertical ring 14000 Gs wet high-intensity magnetic separator can be used in wet processing -1.2 mm(-200 mesh of 30~100%) red ore (hematite and limonite, siderite etc.), manganese ore, ilmenite, chromite, tungsten ore and other kinds of weakly magnetic minerals and metallic minerals, such as quartz, feldspar, nepheline ore, kaolin for removing impurity iron and purification.

Model:

Model	Diameter of revolving	Feeding size (mm)	Feeding density	Processing	Rated background	Rated exciting	Motor	Water	Water	Weight of main engine(t)	Appearance size
	Ring(mm)		(%)	Capacity	Field intensity	Power	Power	Pressure	Consumption		LWH
				(t/h)	(T)	Kw	Kw	MPa	m³/h		(mm)
LHGC-500	500	-1	10-40	0.1-0.3	1.1	16	0.37+0.18	0.1-0.2	0.75-1.5	1.5	180014001320
LHGC-750	750	-1	10-40	0.1-0.5	1.1	21	0.75+0.55	0.1-0.2	1.5-3.0	3	200013601680
LHGC-1000	1000	-1.2	10-40	3.5-7.5	1.1	30.8	2.2+1.1	0.2-0.4	10~20	6	270020002400
LHGC-1250	1250	-1.2	10-40		1.1	37.8	2.2+1.5	0.2-0.4	20-50	14	320023402700
LHGC-1500	1500	-1.2	10-40	20-30	1.1	46.2	4+3	0.2-0.4	50-100	20	360029003200
LHGC-1750	1750	-1.2	10-40	30-50	1.1	65.3	4+4	0.2-0.4	70-160	35	390033003800
LHGC-2000	2000	-1.2	10-40	50-80	1.1	78.3	7.5+5.5	0.2-0.4	100-200	50	420035504200
LHGC-2500	2500	-1.2	10-40	80-150	1.1	96.3	11+11	0.2-0.4	200-400	105	580050005400
LHGC-3000	3000	-1.2	10-40	150-250	1.1	103.6	15+11	0.2-0.4	300-500	150	760065007200

Packaging & Shipping

wooden cases/steel frame,or according to the customer's requirements. Fumigation packaging!

Our Services

12 monthes after-sale service. Best quality with easy maintainess.
