Highest Level GHH 280Kw Frequency Screw Air Compressor
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
315Kw High Pressure Frequency Screw Air Compressor
-
Large Capacity Frequency Air Compressor Approved
-
355Kw 480Hp Direct Driven High Pressure Screw Air Compressor
-
Low Noise Frequency Air Compressor Witn Water-cooling
-
400Kw Direct Driven Vsd Ac Screw Air Compressor
-
450Kw Industrial Frequency Screw Air Compressor For Sale
Product Details
| Condition | New | Type | Screw | |
| Configuration | Other, Stationary, ISO9001 | Power Source | AC Power | |
| Lubrication Style | Oil-less | Mute | No | |
| Place of Origin | Shanghai, China | Brand Name | ZIQI, ZIQI | |
| Model Number | GA-280A/W VFC | Voltage | 380,3000 ,6000,10000/3/50,60 | |
| Dimension(L*W*H) | 3950X2300X2350mm | Weight | 5290KG | |
| Certification | ISO9001 | Warranty | One Year | |
| After-sales Service Provided | Overseas service center available |
Product Description
| Highest Level GHH 280Kw Frequency Screw Air Compressor |
| Product picture |
|
| technical parameter |
| Production Name | Screw air compressor | |
| Model Number | GA-280A/W VFC | |
| Brand Name | ZIQI | |
| Configuration | Stationary | |
Air displacement/ exhaust pressure | mmm/min/MPA | 5.07-50.7/0.7 5.00-50.0/0.8 4.20-42.0/1.0 3.83-38.3/1.3 |
| Compressor series | single stage | |
| Cooling method | A-air Cooling W-watering Cooling | |
Exhaust temperature | ℃ | Air Cooling <Ambient temperature +15℃ Watering Cooling<40℃ |
| Water temperature | ℃ | ≤32 |
| Water pressure | MPa | 0.2-0.6 |
| Noise level | B(A) | 76 2 |
| Transmission | Flexbility direct drive | |
| Electric suppy | V/ph/Hz | 380,3000,6000,1000/3/50,60 |
| Motor Power | KW | 280 |
| Lubricant oil | L | 145 |
| Starting method | Frequency start up | |
| Dimension(L*W*H) | mmxmmxmm | 3950*2300*2350 |
| Weight | Kg | 5290 |
| Exit diameter | mm | 125 |
| Cooling water connetor pipe diameter | mm | 50 |
| Advantages |
|
| Detail images |
![]() |
| Factory & Trade fair & Visiting customer |
![]() ![]() ![]() |
If you chose us, you are bound to have the most advance screw technology and the best service of the world. ziqi provide high quality produces and services for generall industrials , manufacture industrials electricity, architecture, mining, energy, ect, our service network composed of distributors and agencies assigned by local subsidiaries , they are providing perfect services for ZIQI's customers from all over the world. ZIQI Group: Provide the best compressed air system to user Our Products: High efficient, durable, energy saving, enviroment protection |
| Shipment & packaging |
![]() |
| Certification |
![]() |
| FAQ |
Q: Are you trading company or manufacturer ? Q: How long is your delivery time? Q: What is your terms of payment ? Q: How do you make our business long-term and good relationship? |
| If you have any question,welcome to contact to me. |
![]() |
