Economical Handheld Digital Multimeter, AC/DC/Resistance UT51

Name: Economical Handheld Digital Multimeter, AC/DC/Resistance UT51
Brand: UNI-T
SKU: 131399737
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

UNI-T

Model Number:

UT51

Shanghai Sunlight Electronic Technology Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name UNI-T

Model Number UT51

Measuring Current Range 200mA/2mA/20mA/200mA/2A/10A

Measuring Voltage Range 200mV/2V/20V/200V/750V

Measuring Resistance Range 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ

Dimensions 190mm*88mm*34mm

Specifications:

Specifications	Range	Best Accuracy
Model		UT51
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)
AC Voltage (V)	200mV/2V/20V/200V/750V	±(0.8%+3)
DC Current (A)	20mA/200mA/2mA/20mA/200mA/2A/10A	±(0.8%+1)
AC Current (A)	200mA/2mA/20mA/200mA/2A/10A	±(1%+3)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ	±(0.8%+1)
Features
Fused 10A Range		Yes
Transistor		Yes
Diode		Yes
Continuity Buzzer		Yes
Low Battery Display		Yes
Input Impedance for DC Voltage Measurement	10MΩ	Yes
Max. Display	1999	Yes
General Characteristic
Power	9V Battery (6F22)
LCD Size	65mm×33mm
Product Colour	Red and Grey
Product Net Weight	560g (including holster)
Product Size	190mm×88mm×34mm
Standard Accessories	Test Lead, Batteryl, Holster
Standard Individual Packing	Gift Box,English Manual
Standard Quantity Per Carton	20 Pcs
Standard Carton Measurement	535mm×362mm×385mm
Standard Carton Gross Weight	20.5 Kg
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2)

Contrast:

Specifications	Range	Best Accuracy
Model		UT51	UT52	UT53
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)	±(0.5%+1)	±(0.5%+1)
AC Voltage (V)	200mV/2V/20V/200V/750V	±(0.8%+3)	±(0.8%+3)	±(0.8%+3)
DC Current (A)	20mA/200mA/2mA/20mA/200mA/2A/10A	±(0.8%+1)
DC Current (A)	2mA/20mA/200mA/20A		±(0.8%+1)	±(0.8%+1)
AC Current (A)	200mA/2mA/20mA/200mA/2A/10A	±(1%+3)
AC Current (A)	2mA/20mA/200mA/20A		±(1%+3)	±(1%+3)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ /200MΩ	±(0.8%+1)	±(0.8%+1)	±(0.8%+1)
Capacitance (F)	2nF/20nF/200nF/2μF/20μF		±(4%+3)	±(4%+3)
Temperature (°C)	-40°C~1000°C			±(1%+3)
Features
Fused 10A Range		Yes
Transistor		Yes	Yes	Yes
Diode		Yes	Yes	Yes
Continuity Buzzer		Yes	Yes	Yes
Sleep Mode				Yes
Low Battery Display		Yes	Yes	Yes
Input Impedance for DC Voltage Measurement	10MΩ	Yes	Yes	Yes
Max. Display	1999	Yes	Yes	Yes
General Characteristic
Power	9V Battery (6F22)
LCD Size	65mm×33mm
Product Colour	Red and Grey
Product Net Weight	560g (including holster)
Product Size	190mm×88mm×34mm
Standard Accessories	Test Lead, Batteryl, Holster
Standard Individual Packing	Gift Box,English Manual
Standard Quantity Per Carton	20 Pcs
Standard Carton Measurement	535mm×362mm×385mm
Standard Carton Gross Weight	20.5 Kg
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2)
