Home > Instruments & Meters > Meter for Electricity > Multimeter > Handheld Auto-ranging Digital Multimeter, UT136A

Handheld Auto-ranging Digital Multimeter, UT136A

Name: Handheld Auto-ranging Digital Multimeter, UT136A
Brand: UNI-T
SKU: 131399199
Availability: InStock

Handheld Auto-ranging Digital Multimeter, UT136A thumbnail-1

Handheld Auto-ranging Digital Multimeter, UT136A photo-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

UNI-T

Model Number:

UT136A

Contact Supplier Request Quote Chat Now

Shanghai Sunlight Electronic Technology Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name UNI-T

Model Number UT136A

Measuring Current Range 400uA/4mA/40mA/400mA/4A/10A

Measuring Voltage Range 400mV/4V/40V/400V/500V

Measuring Resistance Range 400Ω/4000Ω/40kΩ/400kΩ/4MΩ/40MΩ

Dimensions 72mm*137mm*35mm

Features:

UT136 series are mini handheld auto-ranging digital multimeters that offer users complete functions, stable performance, low power consumption, novel structural design, high degree of safety and reliability, and therefore become an ideal portable tool for maintenance and repairing.

Applicable fields are homes, schools, metallurgy, communications, manufacturing, national defense, electric power, chemical industry, ect, and the series is a best choice for electric circuit/equipment maintenance and repairing.

Specifications:

Specifications	Range	Best Accuracy
Model		UT136A
DC Voltage	400mV/4V/40V/400V/500V	±(0.8%+1)
AC Voltage	400mV/4V/40V/400V/500V	±(1.2%+3)
DC Current	400uA/4mA/40mA/400mA/4A/10A	±(1.0%+2)
AC Current	400uA/4mA/40mA/400mA/4A/10A	±(1.2%+5)
Resistance	400Ω/4000Ω/40kΩ/400kΩ/4MΩ/40MΩ	±(1.0%+2)
Frequency	10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz	±(0.5%+3)
Duty Cycle	0.1%~99.9%	Yes
Features
Diode		Yes
Continuity Buzzer		Yes
Auto Power Off		Yes
Low Battery Display		Yes
Input Impedance for Voltage Measurement	≥10MΩ	Yes
Data Hold		Yes
Max. Display		3999
General Characteristic
Power	9VBattery(6F22)
LCD Size	49mm×18mm
Product Color	Red +Grey
Product Net Weight	About 200g(Battery included)
Product Size	72mm×137mm×35mm
Standard Accessories	Test leads, Battery
Standard Packing	Giftbox, English Manual
Standard Quantity Per Carton	66 Pcs
Standard Carton Measurement	540mm×310mm×350mm
Standard Carton Gross Weight	About 22 Kg

Contrast:

Specifications	Range	Best Accuracy
Model		UT136A	UT136B	UT136C	UT136D
DC Voltage	400mV/4V/40V/400V/500V	±(0.8%+1)	±(0.8%+1)	±(0.8%+1)	±(0.8%+1)
AC Voltage	400mV/4V/40V/400V/500V	±(1.2%+3)	±(1.2%+3)	±(1.2%+3)	±(1.2%+3)
DC Current	400uA/4mA/40mA/400mA/4A/10A	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)
AC Current	400uA/4mA/40mA/400mA/4A/10A	±(1.2%+5)	±(1.2%+5)	±(1.2%+5)	±(1.2%+5)
Resistance	400Ω/4000Ω/40kΩ/400kΩ/4MΩ /40MΩ	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)
Capacitance	4nF/40nF/400nF/4uF/40uF/100uF		±(4.0%+3)
Temperature	‘-40°C~1000°C			±(2.5%+3)
Frequency	10Hz/100Hz/1kHz/10kHz/100kHz /1MHz/10MHz	±(0.5%+3)	±(0.5%+3)	±(0.5%+3)	±(0.5%+3)
Duty Cycle	0.1%~99.9%	Yes	Yes	Yes	Yes
Features
Diode		Yes	Yes	Yes	Yes
Continuity Buzzer		Yes	Yes	Yes	Yes
NCV					Yes
Auto Power Off		Yes	Yes	Yes	Yes
Low Battery Display		Yes	Yes	Yes	Yes
Input Impedance for Voltage Measurement	≥10MΩ	Yes	Yes	Yes	Yes
Data Hold		Yes	Yes	Yes	Yes
Max. Display		3999	3999	3999	3999
General Characteristic
Power	9VBattery(6F22)
LCD Size	49mm×18mm
Product Color	Red +Grey
Product Net Weight	About 200g (Battery included)
Product Size	72mm×137mm×35mm
Standard Accessories	Test leads, Battery, Point type temperature probe(UT136C Only)
Standard Packing	Giftbox, English Manual
Standard Quantity Per Carton	66 Pcs
Standard Carton Measurement	595mm×310mm×350mm
Standard Carton Gross Weight	About 22 Kg
