Specifications
Round Dry Magnetic Tramp Iron SeparatorDry Magnetic Separator
High Magnetic Effect
ISO
|
Round Dry Magnetic Tramp Iron Separator
| |
| 1. Model Name: | CTD |
| 2. Usage: | Iron ore, magnetite ore benefication |
| 3. Permanent magnet: | 1450-9000 gauss |
| 4. Shell Diameter: | 400-1050mm |
| 5. Capacity: | 3-120 ton/hr |
Dry magnetic separators are our company's newly developed high-efficiency and successful magnetic separation equipments. The magnetic system all adopts high performance tin soil neodymium iron boron and ferrite material. With the open type and skillful magnetic circuit design: the highest magnetic induction strength of the cylinder's sorting area can reach above 0.8T; The magnetic field strength is 3-5 times as much as conventional magnetic machine; The magnetic force of the sorting region can achieve the magnetic level of electromagnetic magnetic separator. The sorting cylinder is made of refined wear-resistant stainless steel. Sorting mineral adopts vibrating ore evently to the upper part of the sorting feeder, the roating cylinder throws off the non-magnetic material from the cylinder body, and the magnetic material is subjected to strong magnetic force and attracts to the cylinder, and then the magnetic and non magnetic material are separated easily and precisely by using mine division plate.
The strong magnetic force makes it real for dry magnetic separator to select magnetic and weak magnetic minerals. The equipment has strong processing capacity, wide grain size range of sorting mineral, high separation precision, no blockage; has the advantages of simple structure, convenient maintenance, adn the power consumption is only 20% of the electromagnetic magnetic separator.
Applying the principle that a magnetic material can be attracted by permanent magnet to design semi circular magnetic series, forming a larger magnetic field in the interior of the roller flowed by material. When the materials flow through the magnetic field, magnetic ores are attracted by the magnetic force at once and adsorbed on the surface of the semicircle adsorption roller in the magnetic system. When the magnetic ores are taken to the non-magnetic bottom zone, they are discharged from concentrate mouth under the role of gravity. At the same time, the non-magnetic or lower iron-rate ores can pass through freely from the magnetic field and are discharged from the tailing mouth under gravity.
Equipment Advantages
- Separating without water
- Good separation effect
- Large processing capacity, wide sorting mineral range, high separation precision, no blockage
- Extensive industry application
- High production efficiency
- simple structure, convenient maintenance, power consumption is only 20% of the electromagnetic magnetic separator
Our company, Boyun Machinery, is a high-tech enterprise specializing in manufacturing mining equipments. Main products are magnetic separator, ceramic vacuum filter, vacuum filter, magnetic vacuum filter, vibrating screen, magnetic pulley. Boyun brand machines have been exporting to America, EU, Austrilia and Africa.
Why choose BOYUN company?
Training is FREE to every customer. Whenever you need us, for installation, maintenance, or proper use of our company machines, we will be right there for you. In addition, we provide 1-years warranty to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.
In order to give you a responsible quotation, you can inform us the following information:
1. What's the material you are going to deal with?
2. What's the granularity of the material?
3. What's the granularity of the final products are you going to achive?
4. What's the producing capacity you are going to achieve?
Our engineers will suggest you the most suitable one for you according to your information.
