| Model Name: | PGT Series vacuum disc filter |
| Filtration Area: | 10-96 square meters |
| Capacity: | 0.6-0.85 T/hr.m2 |
| Usage: | Dewatering for various materials like iron ore and non-ferrous metals. |
Application
It is specially designed for dehydration of iron ore concentrate and non-ferrous metals. It is also suitable for coal washing beneficiation, non-metal ore, chemical engineering and environment protection.
How Does it Work
Technical Data
Filter diameter(mm) |
2100 |
3100
|
|||||||||||||||||||||||||||||||||
Filtration area (m2) |
10 |
15 |
20 |
25 |
30 |
35 |
40 |
48 |
60 |
72 |
84 |
96 |
|||||||||||||||||||||||
Filter disc quantity |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
4 |
5 |
6 |
7 |
8 |
|||||||||||||||||||||||
Quantity of each filtration disc |
20 |
||||||||||||||||||||||||||||||||||
Principal shaft power (KW) |
4 |
5.5 |
7.5 |
||||||||||||||||||||||||||||||||
Mixer shaft power (KW) |
35.5 |
7.5 |
11 |
||||||||||||||||||||||||||||||||
Cake discharged way |
reverse blow |
||||||||||||||||||||||||||||||||||
Weight of machine(t) |
10.4 |
11.0 |
11.6 |
12.2 |
12.8 |
13.4 |
14.0 |
18 |
21 |
24 |
27 |
30 |
|||||||||||||||||||||||
Size |
L(mm) |
2335 |
2920 |
3315 |
3705 |
4095 |
4485 |
4875 |
4175 |
4675 |
5175 |
5675 |
6175 |
||||||||||||||||||||||
W(mm) |
2480 |
4280 |
|||||||||||||||||||||||||||||||||
H(mm) |
2690 |
3740 |
|||||||||||||||||||||||||||||||||
Capacity (t/ h) |
0.6-0.85 |
||||||||||||||||||||||||||||||||||
The technical data above mentioned is as referred
Sketch Picture
Working Condition
1,the particle size of solid in the slurry is -100mesh to -400mesh
2,the temperature of slurry is 10-50°C, no corrosion
3,the best concentration of slurry is 35%-65%(metal mineral) or 20%-40%(coal or other lightweight material)
Sketch Picture Of Structure
Filter Cloth Self Cleaning Disc Vacuum Filter With Long Working Life
Installation In Customer's Factory
