XDL-FW1607-A2 Honeycomb Floor Type Auto Blasting Room
For Cleaning Steel Structures, Oil & Gas Tank, Pressure Vessel
1 Features & Summary
- Blasting Room is mainly used for cleaning the surface of oil & gas tanks, and steel structure etc.
- By shot blasting, rust and oxide coat will be removed away and you will get a qualified surface of Sa2.5 and certain roughness.
- This will intensify the steel, improve the antifatigue capacity, add the adhesion of paint film and finally improve the inner and outer quality of steel.
2. Technical Parameters
|
Electrical Power Voltage/Frequency |
Motor |
380V/50Hz |
Control |
220V/50Hz |
|
Size of Blasting Jobs |
Max Size |
13,000×Φ3,200mm |
Max Weight |
10~20 tons |
|
Blasting Booth |
Door Open Size |
5,000×4,500mm |
|
Booth Size L × W × H |
16,000×7,000 ×5,500mm |
|
Blasting Productivity |
Working Time / Day |
8 hr.s |
Blasting Nozzle/ Φ10mm |
2 units |
|
Blasting Area per day |
15~35m2/hr×2×8hr.s =240~560m2 |
|
Surface Quality After Blasting |
Grade |
Sa 2.5 |
Roughness |
45µm~75µm |
|
Steel Shots/Grits |
Size |
1.0mm~1.2mm |
Initial Input |
4,000~5,000 kg |
|
Provided by the client | ||
Abrasive Recycle Type |
Auto Honeycomb floor Shots Recovery System |
|
|
Dust Removing System I for Blasting Room |
Air volume |
42,000~48,000m3/hr |
Power |
45kw |
|
Pulse Jet Dust Collector |
LT4-64 |
|
Dust Emission Density |
80mg/m3 |
|
|
Dust Removing System I for Shot Recycle System |
Air volume |
12,450~15,455m3/hr |
Power |
37kw |
|
Pulse Jet Dust Collector |
LT4-32 |
|
Dust Emission Density |
80mg/m3 |
|
Noise Level |
≤90dB |
|
Illuminance |
≥300Lux |
|
Blasting Room In Bulk and Motor, Gear Reduced Motor & Electrical Control Cabinet in Wooden Case
Blasting Room, Shot Blasting Machine Design, Manufacture and Installation.
Blasting Room, Shot Blasting Machine Expert - Dafeng City Sanxing Machinery Manufacturing Co., Ltd. was founded in 2002 by a highly experienced and academically qualified engineer. We are located in the large industrial cluster of shot blasting machines in China. After several years' development, we have become one of the largest providers of shot blasting machine, blasting room and paint spray booth in China. Since the foundation, we have led the industry in China. For high quality, well design and competitive price, we establish distinguished relationships with our customers and enjoy a good reputation at home and abroad. At Sanxing, we understand that if we would not keep innovating and offer collective service of shot blasting, sand blasting and paint spray service to our customers, we would fail in the market. That is why we succeed in China and will succeed in overseas market. We warmly welcome all customers from all over the world to come to visit us and have successful cooperation.
- What's the name of products do you need to do blasting?
- What's the max size of products and max weight?
- What's the blasting room size do you want?
- What's the productivity you need? or How many blasting nozzle do you want?
- What's the electrical power in your country such as voltage and frequency?
- Do you have special requirements?
- For more information concerned, please contact me directly. I will answer you asap professionally.
Guarantee and After Service
- One Year for shot blasting machine after acceptance from the clients.
- 24 hours technical support by email
- Calling or door to door service
