TNC RF Male Connector Flange Mount 4 Holes Gold Supplier
US$ 0.2 - 0.5
MOQ: 2000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
twl
Model Number:
TNC
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
N Male Connector for 1/2 CableUS$ 0.99 - 1.49MOQ: 500 Pieces -
4.3-10 Male Plug Solder Type Straight Connector for 1/2 Superflex CableUS$ 0.49 - 0.99MOQ: 500 Pieces
-
DIN Female 7/16 Connector Clamp/Solder Attachment For 7/8 Cable CopperUS$ 0.49 - 0.99MOQ: 500 Pieces
-
N Type Male Clamp Plug for 8D-FB LMR500US$ 1.9 - 2.86MOQ: 500 Pieces
-
DIN 7/16 Male Type Clamp Connector for 3/8 Super Flexible CableUS$ 0.49 - 0.99MOQ: 500 Pieces
Place of Origin
Guangdong, China
Brand Name
twl
Model Number
TNC
TNC RF Male Connector Flange Mount 4 Holes Alibaba Gold Supplier
TNC connectors featuring a two stud bayonet-coupling mechanism, which is particularly useful for frequently coupled and uncoupled RF connections with frequencies up to 4 GHz.
| ELECTRICAL DATA | |
| Impedance | 50Ω |
| Frequency range (for connector interface) | DC~4GHz |
| Dielectric withstanding Voltage (at sea level) | 1500V rms, 50Hz (depending on cable) |
| Working voltage (at sea level) | 500V rms, 50Hz (depending on cable) |
| Insulation resistance | ≥ 5000 mΩ |
| Contact resistance | centre contact≤1.5mΩ |
| outer contact: ≤ 1 mΩ | |
| RF-leakage (between 2÷3 GHz) | ≥55 dB |
| MECHANICAL DATA | |
| Coupling nut torque | 7Ncm--28Ncm / 0.6 in.lbs--2.5 in.lbs |
| Coupling nut retention force | ≥450N / 101.2 lbs |
| Contact captivation | ≥27N / 6.1 lbs |
| Durability (matings) | ≥500 |
| ENVIRONMENTAL DATA | |
| Temperature range | -65°C to +165°C |
| MATERIAL DATA | |
| Bodies | Brass--Ni plating |
| Pin contacts | Brass--Au / Ag plating |
| Socket contacts | Copper--beryllium Au / Ag plating |
| Crimp ferrules | Copper alloy--Ni plating |
| Insulator | PTFE |
| Gaskets | Silicone rubber |
Packing
Tinlink will try our best to insure the packing and transportation process, to make sure our customers received the perfect cargo.
We have different packing method to meet our customers requirement.
| Normal Packing |
| Packing Details: Foam + Carton Blister + Carton Vacuumize + Blister + Carton Vacuumize + Foam + Carton |
