Dong Feng Compactor Garbage Truck

Name: Dong Feng Compactor Garbage Truck
Brand: dong feng
SKU: 130966417
Availability: InStock

US$ 23,000 - 28,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Drive Wheel:

4x2

Type:

Compactor

Chengli Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Drive Wheel 4x2

Type Compactor

Transmission Type Manual

Emission Standard Euro 2

Volume 6001 - 10000L

Fuel Type Diesel

Engine Capacity 3900ml

Size 7000,6850*2320*2900

Gross Vehicle Weight 7490

Place of Origin Hubei, China

Brand Name dong feng

Model Number CLW5071ZYS3

Specifications

dong feng compactor garbage truck
chassis: dong feng
engine model: cummins
driving mode:4*2

dong feng compactor garbage truck

Overall dimension(mm)	7000,6850×2320×2900	Gross weight(Kg)	7490
Garbage box dimension(cbm)	6-8m3	Rated loading capacity(Kg)	1200-7000
Approach/departure angle(°)	20/11,20/12	Curb weight(Kg)	6095
Front/rear suspension(mm)	1180/2020,1180/1870	Max speed(km/h)	95
Chassis model	EQ1070TJ9AD3	Steering	Have
Engine model	Engine brand	Displacement	power
ISDe140 30 CY4102-C3C CY4102-D3A CY4102-E3C B140 33 YN38PE-2	Dong Feng cummins engine Dong Feng Chaoyang engine Dong Feng Chaoyang engine Dong Feng Chaoyang engine Dong Feng cummins engine Kun Ming YunNei engine	4500cc 3856cc 3856cc 3856cc 3900cc 3760cc	103kw 88kw 88kw 91kw 103kw 90kw
Fuel	Diesel	Emission standard	Euro III
Axle	2	Tyre number	6
Axle space(mm)	3800	Tyre size	8.25-16,7.50-16, 8.25R16,7.50R16
Axle load(kg)	2845/4645	Front wheelbase(mm)	1835,1750
Leaf spring	11/9+7,8/10+7	Rear wheelbase(mm)	1640,1586
Transmission	6 speeds	Steering	optional
