Alibaba Assurance! Hot Sale Pressure Tank Bladder Vessel
Brief introduction of SWJY Alibaba Assurance! Hot Sale Pressure Tank Bladder Vessel
1.Industrial RO Water Treatment
2.Industrial UF Water Treatment
3.Material: FRP
4.ISO9001; ISO14001
FRP Pressure Water Tank Vessel
durable FRP Resin water tank for industrial use, water softener
Resin Water Sofening Tank
Fiberglass Pressure Tank
FRP Winding Vessel
Applying to residential, commercial and industrial softening and filtering systems.
Our GRP Small or Big Water Tank / Oil Tanker Pressure Vessel
Diameter dimension: From 6" to 83" (155mm to 2100mm)
Specification:
A)Material:
(a). inner shell - Polyethylene (PE) seamless one-piece tank liner
(b). Outer shell - Continuous strands of fiber-glass with high strength epoxy resin
(c). Bottom base - FRP reinforced tripod base
(d). Opening - 4" precision injected model with threaded opening for 21 ", 24", 30 ", 36" diameter tanks
(e). Opening - 6 "Aluminum flange (anti-corrosion coating) opening for 36", 42" ,48", 63" diameter tanks
B)Working Pressure:
(a)≤1.0MPa(150PSI)
C)Working Temperature :≤49°C
D)Maximum Vacuum :127mmHg(5"Hg).
E)Maximum Temperature :40C (104F)
F)Certificates:CE ; ISO9001 etc.
G)Media : water
H)Warranty: 3 years
Application:
All feed water and waste water treatment application, included multi-media filter and softener.
2.Specification
Model | Top opening | Bottom opening | Dia ×height(mm) | Volume (m3) | Weight | Suggestion flow(m3/h) |
| (KG) | ||||||
| 818 | 2.5"thread | No | 200×435 | 0.02 | 2.8 | 0.1~0.3 |
| 835 | 2.5"thread | No | 200×895 | 0.042 | 4 | 0.2~0.4 |
| 844 | 2.5"thread | No | 200×1120 | 0.052 | 5 | 0.2~0.5 |
| 1035 | 2.5"thread | No | 250×895 | 0.066 | 5.5 | 0.4~0.8 |
| 1044 | 2.5"thread | No | 250×1120 | 0.083 | 7 | 0.4~1.0 |
| 1054 | 2.5"thread | No | 250×1380 | 0.101 | 8.3 | 0.5~1.2 |
| 1065 | 2.5"thread | No | 250×1550 | 0.12 | 9 | 0.6~1.5 |
| 1252 | 2.5"thread | No | 300×1330 | 0.131 | 9 | 1.0~2.0 |
| 1265 | 2.5"thread | No | 300×1640 | 0.161 | 11.5 | 1.5~2.5 |
| 1354 | 2.5"thread | No | 325×1390 | 0.172 | 11.5 | 1.8~2.5 |
| 1465B | 4''thread | No | 350x1660 | 0.247 | 15.5 | 2.0~3.0 |
| 1465 | 2.5"thread | No | 350×1660 | 0.247 | 15.5 | 2.0~3.0 |
| 1665 | 2.5"thread | No | 400×1660 | 0.307 | 19 | 2.5~4.5 |
| 1665B | 4"thread | No | 400×1660 | 0.307 | 19 | 2.5~4.5 |
| 1865 | 4"thread | No | 450×1660 | 0.375 | 21 | 4.5~5.0 |
3.Material:
(a). inner shell - Polyethylene (PE) seamless one-piece tank liner
(b). Outer shell - Continuous strands of fiber-glass with high strength epoxy resin
(c). Bottom base - FRP reinforced tripod base
(d). Opening - 2.5" & 4" precision injected model with threaded opening for 8 " to 36" diameter tanks
(e). Opening - 6 "Aluminum flange (anti-corrosion coating) opening for 36" to 63" diameter tanks
4.Features
1) Corrosion resistance, 2) Easy and convenient installation 3) beautiful appearance. 3) High pressure, high capacity 4) FRP tank is for industrial water treatment or residential water softener. 5) High pressure. Max pressure: 10 bar 6) High capacity. Capacity: 0.2- 100T/H 7) High quality 8) Tank color: Natural or blue (customize color available) 9) Max temperature: 120F 10) Tank inner liner: PE or ABS 11) Diameter varies.
5. Application
Water supply and wastewater treatment industry, light industry, chemical industry, electronics, petrochemical, pharmaceutical, food, and other industrial fields.
Color: Different colors are available, deep blue, sky blue, gray, natural color, black
Soft water tank vessel production line
Big pressre water tank vessel production line
Q: Are you a trading company or a manufacture factory?
A: Our factory is one of the biggest FRP products, FRP machines manufacturer in China
Q: Can your factory customize the machine for clients ?
A: Yes, we can.
Q: What is your payment terms ?
A: Normally,50% as the deposit first by T/T, the rest 50% will be paid before shipping by T/T. Or by clients' requirement.
Q: How about after-sales service ?
A: 1 year free warranty, Lifetime technical service support.
Q: How can I install the production line and get a commissioning ?
A: We may send our engineer for installation and commissioning, but relevant cost will be paid by you.
Q:Have you some videos where we can see the line producing?
A: Yes, we can provide some videos
Any enquiry please feel free contact us.
