Outboard Propeller:
We supply all brands of outboard propeller :
YAMAHA,MERCU-RY,HONDA,TOHATSU,SUZUKI and EVINRUDE etc.
We still can manufacture as your drawing or example.
outboard propellers, which includes: an axis of the shell is made of metal material, with the number of its external peripheral pockets, the pockets are set apart and equidistant ring extending from the axial extension of the shell axis, the axis central of the shell form a hole for the motor drive shaft to through link,. The margin of the hole axis and the number of pockets in the cavity is formed between the chamber to supply gas emissions; a plurality of helical blades are made of plastic material, the end of the helical blade segment is part of the formation of a card system for embedded cross-axial direction along the axis of the shell at the pockets in; by the above, the metal shell and spiral blades to form a composite material of the propeller.
| No. | Material | Power(HP) | Diameter×Pitch -Coupling(inch) |
|
| 1 | Aluminium Alloy | 2 | 7 1/4 X 5-A | |
| 2 | 4~5 | 7 1/2 X 7-BA | ||
| 3 | 9.9~15 | 9 1/4 X 8-J | ||
| 4 | 9.9~15 | 9 1/4 X 9-J | ||
| 5 | 25~30 | 9 7/8 X10 1/2-F | ||
| 6 | 40 | 11 1/8 X 13-G | ||
| 7 | 48~50 | 11 5/8 X 11-G | ||
| 8 | 60 | 13 1/2 X 15-K | ||
| 9 | 85~115 | 13 1/4 X 17-K | ||
| 1 | Stainless Steel | 40~50 | 13 1/8 X 14-G | |
| 2 | 60 | 13 1/2 X 15-K | ||
| 3 | 85~115 | 13 X 17 - K | ||
| 4 | 150~250 | 13 3/4 X 17-M2 | ||
