Help CenterGs-300-A Paint Booth Spray Booth for Water Paint, With Digital Control
Related Products
-
Gs-300-B Standard Model Spray BoothNegotiableMOQ: 1 Set -
GS-400 Gas Burner Spray BoothUS$ 10,000 - 12,150MOQ: 1 Set
-
GS-500 Gas Burner Spray Booth With Fire Resistant Lock and Digital ControlUS$ 13,000 - 17,000MOQ: 1 Set
-
GS-870 Mini Bus Spray BoothUS$ 13,850 - 15,200MOQ: 1 Set
-
GS-1500 Big Bus Spray BoothUS$ 26,000 - 28,500MOQ: 1 Set
Room body
Outside Dimension: L7000*W5400*H3750;(mm);
Inside Dimension: L6900*W3900*H2800;(mm)
Wall panel: Snow white powder-painted steel plate+EPS, total thickness: 50MM. Powder-painted steel plate is 0.476MM thickness
Base and floor: Steel assemble, 5 rows of grills.
Driving lamp: 4 pcs diamond plate
Personal door: 1-fold with sight windows,pressure lock,size: W680*H2000(mm)
Main door: 3-fold type without edge door, with sight windows, size: W3000*H 2700 (mm)
Air delivery system
Intake fan: 1 set 7.5kw professional turbo fan, air capacity : 25000M³/H (Siemens model)
Exhaust fan: 1 set 7.5kw professional turbo fan, air capacity : 25000M³/H (Siemens model)
(Siemens model)
Exhaust pipe: 4 M straight pipe, 2 pcs small elbow.
Manual VCD: 2 set
Smoke pipe: 4 M straight pipe; 2 pcs small elbow.
Burner: RIELLO/RG5S Max.Heating productivity: 260000K cal/H
Heat exchanger: Max working temperature: 60-80 °C
Filter system
Ceiling filter: 6 SETS filter holding net installation model, holder is made by aluminum.
Floor filter: 5 SETS, installed horizontally
Pre-filter: 2 SET, bag model filter
Lighting system
Ceiling light: 10UNITS×4PCS×40W=40PCS×40W
Side light: 8UNITS×2PCS×40W=16PCS×40W, installed vertically.
Control system
Electric cabinet: Main components made in China with good quality; With overheat, overload, phase-absence protecting; Motor starts directly,with constant temperature spraying function.
Total power: 25KW,380V/220V 60Hz
Water paint system: 8 units*5pcs=40 pcs air nozzle, equipped with 6 sets of 0. 55kw fan to supply the air.
