AYQ Preset Torque Driver AYQ-0.6/1.2/3/6 Digital Torque Meter
Description
AYQ Idling torque screwdriver with torque requirements for tightening the screw fastening the workpiece.
Clockwise operation of the product,value can be pre- set torque.
Exceeds the set value screwdriver idling,priority control efforts can be threaded fastening.
Characteristic
1.It can preset torque value, and has a sound alarm. When the fastener of tightening torque reaches the preset torque value, can automatically hear" click" sound, and feeling the vibrations associated with significant, suggesting the work completed. Force is removed, the automatic reset all related parts.
2. clockwise direction and double direction automatic switching, simple and convenient to use.
3. To adopt scale circle with a scale wheel to make the scale line clear and accurate.
4.Made of aluminum alloy ,durable and a long service life.
5. The preset torque driver in accordance with GB/T 15729-2008 relevant provisions.
6. With 2 cross screwdriver blades inside,let the clients to measuring items according to replace the screwdriver head as they need.
Technical parameters
Model |
AYQ-0.6 |
AYQ-1.2 |
AYQ-3 |
AYQ-6 |
|
Range |
0.1~0.6(N.m) |
0.2~1.2(N.m) |
0.5~3(N.m) |
1~6(N.m) |
|
Division value |
0.01N.m |
0.02N.m |
0.05N.m |
0.1N.m |
|
Precision |
±5% |
||||
Size&Shape |
161mm |
186mm |
|||
Outer diameter of handle |
Φ26mm |
φ31mm |
|||
Joint dimension |
6.35 hex union |
||||
Net weight |
About 0.3Kg |
About 0.4Kg |
|||
Structure
