Digital Micro Ohm Meters UNI-T UT620B low resistance 10uohm Four-wire measurement resistance meter wire length tester
Applications:
Testing the resistance of metal coating, electromotor, and the winding resistance of small-sized transformer.
Point of junction of earthing system; the integrity of welding contact; breaker and switch; the connection of
spacecraft and the track; amphenol connector and conductor jointing; multi-cell battery; the generatrix of
switchboard; contact resistance of component like relay; metallic material; conductor resistance of wires and
cables; the ground resistance of the PEM LK of vessels, vehicles and aircrafts.
Features:
1. Low resistance range: 0.5mΩ~6kΩ;
2. Tesing 10A to increase the accuracy;
3. The minimum resolution 1 uΩ;
4. Bacis accuracy: 0.25%, four-wire testing;
5. Top and bottom testing, making it convenient to classify component, and judge automatically whether the object is standard or not;
6. Unique function of designing wire length , the unit meter and inch can be changed freely;
7. Chargable battery inside, long working life;
8. The data can be storage, read, and deleted. Data storage is 1000
9. USB interface.
Contrasrt
| Specification | Range | Best Accuracy | |
| Model | UT620A | UT620B | |
| Minimum Resolution | 10uΩ | √ | √ |
| Resistance(Ω) | 120.00mΩ/5A | ±0.25%+25dgts | ±0.25%+25dgts |
| 600.00mΩ/1A | ±0.25%+25dgts | ±0.01%+20dgts | |
| 6.0000 Ω/100mA | ±.25%+25dgts | ±0.01%+20dgts | |
| 60.000Ω/10mA | ±0.25%+25dgts | ±0.01%+20dgts | |
| 600.00Ω/1mA | ±0.25%+25dgts | ±0.1%+25dgts | |
| 6.0000KΩ/100uA | ±0.75%+30dgts | ±0.25%+30dgts | |
| Features | |||
| LCD Counts | 60000 | 60000 | |
| Four-wire measurement | √ | √ | |
| Wire length measurement | √ | √ | |
| High/Low limit Alarm | √ | √ | |
| Data Storage | 1000 | 1000 | |
| USB Data Transfer | √ | √ | |
| Manual Range | √ | √ | |
| Backlight | √ | √ | |
| Data Hold | √ | √ | |
| Relative Value | √ | √ | |
| Low Battery Display | √ | √ | |
| GENERAL CHARACTERISTICS | |||
| Power | Lithium Battery 7.4V4000mAh, Rechargerable | ||
| LCD Size | 116mm × 87.5mm | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 1.5 Kg | ||
| Product Size | 268mm × 168mm × 60mm | ||
| Standard Accessories | Kelvin Clips(Red&Black)×1, Power Adaptor×1pcs, USB Cable,Software CD | ||
| Standard Individual Packing | Gift Box, Carrying Bag, English Manual | ||
| Standard Quantity Per Carton | 5PCs | ||
| Standard Carton Measurement | 390mm × 370mm × 285mm | ||
| Standard Carton Cross Weight | 11.5 Kg | ||
| Optional Accessories* | |||
| Four-Wire Test Probes(Red&Black)×1 | |||
Fitting
1. Kelvin Clips(Red&Black)×1,
2. Power Adaptor×1pcs,
3. USB Cable,Software CD,
4. Four-Wire Test Probes(Red&Black)×1*
(Julie Zhou)
