UNI-T UT18A Auto Range Voltmeter Voltage Tester Meter and Continuity Test With LED Indication and No Battery Detection
Negotiable
MOQ: 5 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT18A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT595 Ramp Slope RCD Phase Consequence Loop/Line Impedance Insulation Resistance Earthing Continuity TesterNegotiableMOQ: 1 Piece -
Uni-t Leakage Protection Switch Tester UT581 RCD Measurement Leakage Circuit Breaker AUTO RAMP FunctionNegotiableMOQ: 1 Piece
-
Portable Handheld LCR Meters UNI-T UT611 Inductance Capacitance Resistance Frequency Tester With Series/Parallel Mode LCR MetersNegotiableMOQ: 1 Piece
-
Portable Handheld LCR Meter 10KHz Inductance Capacitance Resistance UNI-T UT611NegotiableMOQ: 1 Piece
-
TFC-1000L Frequency Meter 1GHz a Channel High Resolution Frequency CounterUS$ 1 - 50MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT18A
Display Type
Digital Only
Measuring Range
12V ~ 690 V
Accuracy Class
0.5
Operating Temperature
-10~+65
Dimensions
272mm*85mm*31mm
UNI-T UT18A Auto Range Voltmeter Voltage Tester Meter and Continuity Test with LED Indication and No Battery Detection
Detailed
UT18 series of test pen with measuring AC and DC voltage (including the three-phase alternating current) measurement, phase of three-phase AC power indicator, on-off test, RCD test, single pen measurement (can determine the zero line or wire), self checking, no battery detection and other functions.
Contrast
| Specifications | Range | Best Accuracy | |
| Model | UT18A | UT18B | |
| LED AC/DC Voltage Indication (V) | 12V | 8V±2V | 8V±2V |
| 24V | 18V±2V | 18V±2V | |
| 50V | 38V±4V | 38V±4V | |
| 120V | 92V±6V | 92V±6V | |
| 230V | 174V±8V | 174V±8V | |
| 400V | 320V±10V | 320V±10V | |
| 690V | 550V±15V | 550V±15V | |
| Phase Rotation Test | Operating Voltage: 100V~690V | √ | √ |
| Frequency:50Hz~ 60Hz | |||
| Single Lead(L2)Voltage Detection | Operating Voltage:100V~690V | √ | √ |
| Frequency: 50Hz~ 400Hz | |||
| Continuity Test | Resistance: 0~100KΩ | √ | √ |
| Beeper and LED light Indicator | |||
| RCD Test | Operating Voltage: 230V(50Hz-400Hz) | √ | |
| Polarity Detection | Positive & Negative | √ | √ |
| self-inspection | All LED or LCD indicator | √ | √ |
| No power Test | Operating Voltage: 50VAC/120VDC~690VDC/AC | √ | √ |
| Features | |||
| IP65 | √ | √ | |
| Auto Range | All Range | √ | √ |
| Work Light | All Range | √ | √ |
| Low Battery Indication | Voltage Range: 2.2V-2.4V | √ | √ |
| Exceed Voltage | Voltage Range: 713V-788V | √ | √ |
| Auto standby | standby current <10uA | √ | √ |
| Silent mode | All Range | √ | √ |
| General Characteristic | |||
| Power | 1.5V Batteries(R03)× 2 (not included) | ||
| Product Color | Red and Grey | ||
| Product Net Weight | 260g | ||
| Product Size | 272mm×85mm×31mm | ||
| Standard Accessories | Batteries | ||
| Standard Individual Packing | Blister, English Manual | ||
| Standard Quantity Per Carton | 30PCs | ||
| Standard Carton Measurement | 440mm × 295mm × 455mm (0.079 CBM Per Standard Carton) | ||
| Standard Carton Gross Weight | 17Kg | ||
Fitting
Batteries (not included)
