Portable Handheld LCR Meters UNI-T UT611 Inductance Capacitance Resistance Frequency Tester with Series/Parallel Mode LCR Meters
Introduction
UT610 series is stable, safe and reliable handheld autorange LCR digital bridge table. It is to measure inductance, capacitance, resistance of professional instruments, with low power consumption, high accuracy, speed and other characteristics. String and measurement mode, the measurement quality factor components, loss, phase angle, under the equivalent resistance measurement and DC resistance measurement, inductors, capacitors, resistors communication model which can provide up to five kinds of measuring frequency, to better meet the actual needs.
Suitable for a wide range of inductance laboratories, production lines, maintenance and teaching, capacitance, resistance measurements and screening, it is the ideal tool for maintenance of the majority of users.
Contrasrt
| Specification | Range | Best Accuracy | |
| Model | UT611 | UT612 | |
| Inductance (H) | 600uH-200H | ±(0.5%+5) | |
| 20uH-2000H | ±(0.5%+5) | ||
| Capacitance (F) | 600pF-10mF | ±(0.5%+5) | |
| 200pF-20mF | ±(0.5%+5) | ||
| Resistance (Ω) | 60Ω-20MΩ | ±(0.5%+5) | |
| 20Ω-200MΩ | ±(0.3%+5) | ||
| Test Frequency (Hz) | 100Hz/120Hz/1KHz/10KHz | √ | |
| 100Hz/120Hz/1KHz/10KHz/100KHz | √ | ||
| Operational Voltage | 0.5Vrms | √ | |
| 0.6Vrms | √ | ||
| Test Parameters | L/C/R/DCR/Q/D/θ/ESR | √ | √ |
| Features | |||
| Display Count | 6000 | 20000 | |
| D/Q Display Count | 1000 | 2000 | |
| D/Q Resolution | 0.001 | √ | √ |
| Auto Range | √ | √ | |
| Real-Time Display Test Frequency | √ | √ | |
| Measurement Mode | Series/Parallel | √ | √ |
| Auto Power Off | √ | √ | |
| Low Battery Indication | ≤6.8V | √ | √ |
| Data Hold | √ | √ | |
| Relative Mode | √ | √ | |
| USB Interface | √ | ||
| USB Interface/PC Data Records | 60000 | ||
| Data Storage | 1000 | ||
| LCD Backlight | √ | √ | |
| Analogue Bar Graph | 30 | 26 | |
| Deviation Ratio Measurement | √ | ||
| Comparsion Function | √ | √ | |
| Calibration Function | √ | √ | |
| Output Impedance | 120Ω | √ | √ |
| Auto LCR Smart Check and Measurement | √ | √ | |
| General Characteristic | |||
| Power | 9V Battery(6F22) or USB | ||
| LCD Size | 40 X 63mm | ||
| Product Colour | Red and Grey | ||
| Product Net Weight | 374g | ||
| Product Size | 96 X 193 X 47mm | ||
| Standard Accessories | UT611-Battery,SMD Test Clamp, | ||
| UT612-Battery,SMD Test Clamp,USB Interface Cable,Multi-Purpose Socket,PC Software CD | |||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 24 PCs | ||
| Standard Carton Measurement | 610mm X 450mm X 355mm (0.097 CBM Per Standard Carton) | ||
| Standard Carton Cross Weight | 22.3Kg | ||
| Optional Accessories* | |||
| USB Power Adapter | |||
Fitting
1. Battery, (not included)2. SMD Test Clamp,
