Portable Handheld LCR Meter 10KHz Inductance Capacitance Resistance UNI-T UT611
Features:
Display Count: 6000
D/Q Display Count: 1000
D/Q Resolution: 0.001
Auto Range: √
Real-Time Display Test Frequency: √
Measurement Mode: Series/Parallel
Auto Power Off: √
Low Battery Indication: ≤6.8V
Data Hold: √
Relative Mode: √
Data Storage: 1000
LCD Backlight: √
Analogue Bar Graph: 30
Comparsion Function: √
Calibration Function: √
Output Impedance: 120Ω
Auto LCR Smart Check and Measurement: √
Specification:
Model: UT611
Inductance (H): 600uH~200H ±(0.5%+5)
Capacitance (F): 600pF~10mF ±(0.5%+5)
Resistance (Ω): 60Ω~20MΩ ±(0.5%+5)
Test Frequency (Hz): 100Hz/120Hz/1KHz/10KHz
Operational Voltage: 0.5Vrms
Test Parameters: L/C/R/DCR/Q/D/θ/ESR
General Characteristic:
Power: 9V Battery(6F22) or USB (not included)
Product Net Weight: 374g
Product Size: 96 * 193 * 47mm
LCD Size: 40 * 63mm
Product Colour: Red and Grey
Package Size: 29 * 22.5 * 7.5cm / 11.5 * 8.9 * 3in
Package Weight: 1109g / 2.4lb
Package List:
1 * UNI-T UT611 LCR Meter
1 * SMD Test Clamp
1 * English Manual
1 * Carrying Bag
