Uni-t Leakage Protection Switch Tester UT581 RCD Measurement Leakage Circuit Breaker AUTO RAMP Function

Name: Uni-t Leakage Protection Switch Tester UT581 RCD Measurement Leakage Circuit Breaker AUTO RAMP Function
Brand: UNI-T
SKU: 130808871

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

UNI-T

Model Number:

UT581

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name UNI-T

Model Number UT581

Digital RCD (ELCB) Testers UNI-T UT581 AUTO RAMP function Leakage Circuit Breaker leakage protection switch tester

Features

UT580 series Digital RCD (ELCB) Testers

1. AUTO RAMP function to test trip time and trip current;

2. 3 LED lamp for connectivity check;

3. Auto Data Hold function to display trip time for several seconds after each test;

4. Phase Switch Selection (0°and 180°) to test shortest triggering time;

5. Overload indication – “OL”;

6. Environmental: no battery is required. Powered directly from testing subject (A/C 220V/50Hz);

7. Fused protection and double insulation structure for extra safety;

8. ntelligent micro-processing controller to provide high-accuracy and reliability;

9Ergonomic design;

10Comply with IEC 61010-1 CAT III 300V; IEC 61557-1,5; IEC 61010-2-31.

Specification

Specifications	Range			Best Accuracy
Model				UT582	UT582
RCD Measurement	Range Select	Rated Operating Current	Trip Time
	X 1/2	10mA/20mA/30mA/100mA/ 300mA/500mA	1000mS	√	√
	X 1	10mA/20mA/30mA/100mA/300mA	1000mS	√	√
	X 1	500mA	300mS	√	√
	X 5	10mA/20mA/30mA	300mS	√	√
	250mA	250mA	40mS	√
	AUTO RAMP	10mA/20mA/30mA/100mA/ 300mA/500mA	300mS		√
	Trip Current Accuracy			±(2%+8)	±(2%+8)
	Trip Time Accuracy			±(0.6%+4)	±(0.6%+4)
	Trip Time Resolution	1mS		√	√
	Operational Voltage(Freq.)	195V-253V(50Hz)		√	√
Features
Display Count				1000	1000
Data Hold				√	√
Phase Switch	0°and 180°			√	√
Connections Check Function	Lamps Indication			√	√
AUTO RAMP Function	Test the trip time and trip current				√
Disconnect Buzzer				√	√
Over-Range Display	OL			√	√
Fused				√	√
Mis-Operation Buzzer				√	√
Power off Buzzer				√	√
Full Icon Display				√	√
General Characteristic
Power	No Battery is required
LCD Size	71mm X 34mm
Product Color	Red and Grey
Product Net Weight	400g
Product Size	160mm X 100mm X 71mm
Standard Accessories	Test Lead,Carrying Bag
Standard Individual Packing	Gift Box,English Manual
Standard Quantity Per Carton	20 PCs
Standard Carton Measurement	440mm X 430mm X 335mm (0.063CBM Per Export Carton)
Standard Carton Gross Weight	14Kg
