New Arrival Multi-mode Leeb ultrasonic thickness gauge MT600 High-accuracy Automatically V-Path correction



New Arrival Multi-mode Leeb ultrasonic thickness gauge MT600


The model MT600 is a multi-mode ultrasonic thickness gauge. Based on the same operating principles as SONAR, the instrument is capable of measuring the thickness of various materials with accuracy as high as 0.1/0.01 millimeters.
The multi-mode feature of the gauge allows the user to toggle between pulse-echo mode (flaw and pit detection), and echo-echo mode (eliminate paint or coating thickness).



MAIN FUNCTION

1. Multi-mode: Pulse-Echo mode and Echo-Echo mode, it can do thickness testing via getting through the coating thickness without calculate the coating thickness.
2. Capable of performing measurements on a wide range of material, includingmetals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.
3. With Probe-Zero function and Two-Point Calibration function, it can correct thesystem error automatically.
4. With Sound-Velocity-Calibration function, it can improve the accuracy.
5. Designed with high-accuracy real-time clock to realize accuracy thicknessmeasurement
6. Automatically V-Path correction to compensate the nonlinearity of dual probe when testing the thickness.
7. With high-performance CPU chip, it can do ten measurements readings persecond.
8. With colorful large display 320X240 TFT LCD, it can show information rich, directly and clear. With adjustable brightness backlight, it can be used easily under the environment of dimly light and strong sunlight.
9. With large memory, it can save 10,000 thickness measurements
10. With internal Bluetooth module and USB 2.0 communication port
11. The instrument can update procedure online.


CONFIGURATION

Standard Configuration                        1

Main body                                          1

Probe P5EE (5MHz)                            1

Couplant                                             1

Instrument Case                                  1

Operating Manual                                 1

Alkaline battery                                    2             AA Size


Optional Configuration

Probe N05/90° (5MHz)

Probe N05 (5MHz)

Probe N07 (7MHz)

Probe HT5 (5MHz)

Data pro software                                 1

USB communication cable                    1



Portable bluetooth thermal printer          1              including charger,manual and other parts


SPECIFICATION

Display:  Colorful large display 320X240 TFT LCD with adjustable backlight
Range:  Pulse-Echo mode: (0.65-600)mm (in Steel) Echo-Echo mode: (2.5-100)mm (in steel with P5EE probe) Sound Velocity Range: (100~9999) m/s.
Resolution:   0.1mm/0.01mm
Accuracy:  ±0.04mm (<10mm); ±0.4%Hmm(>10mm) H refer to the thickness of workpiece
Measurement Period:   ten times per second
;Memory for up to 100 files (up to 99 values for each file) of stored values.
Power Source:  Two “AA” size, 1.5 Volt alkaline batteries. 100 hours typical operating time (EL backlight off).
Communication:  USB 2.0 and Support Bluetooth
Language:  English/ Chinese
Outline dimensions:  150mm×74mm×38mm.
Weight:  295g

Operating Conditions

Operating Temperature:   0- +50;
Storage Temperature-20- +70
Relative Humidity ≤80%;
The surrounding environment should avoid of vibration, strong magnetic field,corrosive medium and heavy dust.

Transducer Selection

Model

Freq


MHZ

Diam


mm
 Measuring Range Lower limit Description
N02 2.5 14 Echo-Echo mode:(3-30)mm for MT180  (3-60)mm for MT190 Φ20mm×3.0mm Through Coating Measurement
N05 5 10 1mm~600.0mm(In Steel) Φ20mm×3.0mm Normal Measurement
N05/90° 5 10 1mm~600.0mm(In Steel) Φ20mm×3.0mm Normal Measurement
N07 7 6

0.65mm~200.0mm
 (In Steel)
Φ15mm×2.0mm For thin pipe wall or small curvature pipe wall measurement
