WG68 Precision Gloss Meter, store 50000 testing records, each prototype with 500 testing data
WG68 gloss meter is produced according to the national verification regulation of JJG696 standard, adopt long life light source, good repeatability, small volume, high precision and good stability. It is mainly used coatings, printing ink, paint, paint, wood, marble, granite, polishing brick, brick of pottery and porcelain, plastic, paper, metal and non-metallic materials to the surface of the mirror gloss measurement, more stable performance, more durable, more comfortable;
Gloss meter WG68 Functional Description
(1) One button to complete triangle measurement: one operation can complete three angle measurement; Measuring light incident angle meet ISO 2813 three measuring light incident angle. Three incidenct angle of mirror gloss meter is 20 °, 60 °, 85 ° respectively;
(2) Optional angle mode: choose measuring angle or angle combination according to user needs.
(3) Manually entering standard samples gloss data;
(4) Humanized design, good man-machine communication interface;
(5)Three angle can store 50000 testing records, storage structure is: 100 prototypes, each prototype with 500 testing data;
(6) Data browsing and viewing function;
(7) The machine has automatic shutdown function, low power warning functions, full data storage hint functions;
(8) USB communication interface to communicate with PC;
(9) PC software can be extended more functions.
Attachment Description
(1) Power adapter: standard + 5V, 2A external power supply;
(2) Standard board: provide calibration criterion.
(3) USB cable: connect instrument to PC.
WG68 Specification:
Specification |
Unit |
Triangle Gloss Meter |
Measuring Angle |
degree |
20° 60° 85° |
Measuring Range |
GU |
20°:0-2000 60°:0-1000 85°:0-160 |
Measuring Spot |
mm |
20°: 10x10 60°:9x15 85°:5x18 |
Measuring Spot |
GU |
0-1000:0.1 1000-2000:1 |
Repeatability |
GU |
0-100:0.2 >100:0.2% |
Indication Error |
GU |
±1.5 |
Zero Error |
GU |
0.2 |
Working Temperature Range |
℃ |
10℃ - 40℃ |
Storage Temperature Range |
℃ |
-10℃ - 70℃ |
Humidity Range |
|
Relative humidity less than 85%,without condensation |
Power Adapter |
|
Section 2 5 alkaline batteries/power adapter |
Volume |
mm |
159x49x72 |
Weight |
g |
500 |
