RIGOL MSO1104Z-S 100MHz Mixed Signal Oscilloscope 4 analog channels 100MHz
The MSO1000Z Series is the new economic level Digital Oscilloscope from Rigol to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities. The MSO1000Z 4 channel oscilloscopes come in 70 or 100 MHz versions with a 7 inch display and Rigol's UltraVision technology and a 16 bit digital input port for mixed signal applications as well as a host of options. Add the optional analysis, decoding, deep memory, and integrated 2 channel waveform generator for a powerful 4 channel scope at an exceptional price.
Features and Benefits
- 100MHz Bandwidth, 4 analog channels
- 16 digital channels for Mixed Signal analysis
- 1G Sa/s Real-time Sample Rate
- 12Mpts (Std.) and 24Mpts (Opt.) Memory Depth
- Innovative "UltraVision" technology
- Up to 30,000wfms/s Waveform Capture Rate
- 7 Inch WVGA (800x480), multiple intensity levels waveform display
- Built in 2 channels 25MHz waveform Generator
-
Model
MSO1104Z-S
Bandwidth
100 MHz
Analog Channels
4
Sample Rate
1GSa/s (Single-channel), 500MSa/s(Dual-channel), 250MSa/s(Fulll-channel)
Max Memory Depth
12Mpts(standard) ,24Mpts(option)
Max. Waveform Capture rate
Up to 30,000 wfms/s
Real Time waveform Record and Replay
Up to 60, 000 Frames(Opt.)
Std. Probes
RP2200 150MHz BW Passive Probe:4 sets
Built in 2 Ch Source
Yes
16 Digital Channels for
Mixed Signal Analysis
Yes
- Advanced functions:
- Compact size, Light weight, Easy to Us
- 4 analog channels, 16 digital channels (for MSO1000Z and MSO upgradable for DS1000Z Plus)
- UltraVision: Deeper memory(Std.12Mpts,Opt.24Mpts)
- UltraVision: Up to 30,000 wfms/s Waveform capture rate
- UltraVision: intensity graded color display
- UltraVision: waveform recording and playback functions (optional)
- A variety of trigger functions
- Built-in dual-channel 25 MHz source(MSO1XX4Z-S and DS1XX4Z-S Plus)
- Optional serial bus trigger and decoding functions(RS232/UART, I2C, SPI)
- Mixed Signal Analysis with analog and digital channels (MSO)
- Easy to be grouped and labeled for digital channels (MSO)
- Serial bus triggering and decoding on digital channels (MSO)
- Serial bus triggering and decoding on digital channels (MSO)
- Package:
- 1 SDS1102CML scope,
- 2 probes,
- 1 USB Cable,
- 1 Power cord,
- 1 Quick start (user manual),
- 1 CD.
(Julie Zhou)
