Siglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/s

Siglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/s



Features and Benefits:
 Up to 100MHz Bandwidth 500MSa/s sample rate
 7''TFT-LCD display, 8*18 grids
 Channels: 2CH+1EXT
 500MSa/s samplinge rate, 32Kpts memory depth
 6 digits hardware frequency counter, real time counting display
 Support SCPI programming command control
 Interface: USB Device, USB Host, RS-232, Pass/Fail
 Unique digital filter and data recorder function
 Embedded 12 languages, online help, one key storing and one key printing

Specifications:

Model

SDS1022DL

SDS1052DL

SDS1102DL

SDS1202DL

Bandwidth

25MHz

50MHz

100MHz

200MHz

Channels

2CH+1EXT

Real time sampling rate

500MSa/s

Equivalent sampling rate

10GSa/s

50GSa/s

Memory depth

32k

Rise time

< 14ns

< 7ns

< 3.5ns

< 1.8ns

Input impedance

1M ohm II 17pF

Time base range

25ns/div-50s/div

10ns/div-50s/div

5ns/div-50s/div

2.5ns/div-50s/div

Scan: 100ms-50s/div

Vertical sensitivity

2mV-10V/div

Vertical resolution

8bit

Trigger source

CH1, CH2, Ext, Ext/5, AC Line

Trigger types

Edge, Pulse, Video, Slope, Alternative

Math Operation

+, -, ×, ÷, FFT

Digital filter

High pass, Low pass, Band pass, Band Stop

Max input voltage

±400V (DC+AC Pk-Pk), CAT 1, CATII

Internal storage

2 groups of reference waveform, 20 groups of settings, 10 groups of waveforms

External storage

Bitmap save, CSV save, Waveform save, Setting save

Language

English, French, German, Russian, Spanish, Simplified Chinese, Traditional Chinese, Portuguese, Japanese, Korean, Italian, Arabic

Interface

USB Host, USB Device, RS-232, Pass/Fail out

Display

7 inches(178mm) color TFT(480*234) LCD

Power

AC 100-240V, 45Hz-440Hz, 50VA Max

PC software

Can through the computer remote control oscilloscope, extraction waveform analysis data

Remark

With original source seamless connection, form signal collection, produce integration system

Detailed performance parameters and technical index please refer to SDS1000DL series Datasheet

Application:

  1. Electronic circuit design and debugging

  2. Electrical circuit function test

  3. Inspect instantaneous signal

  4. Industrial control and measuring

  5. Products quality control

  6. Education and traininSiglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/sSiglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/sSiglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/sSiglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/sSiglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/sSiglent 100MHz SDS1102DL Digital Storage Oscilloscope 2 channels 7"display 32Kpts memory depth 500Msa/s
