2.8'' Pocket Oscilloscope ARM DSO201 DSO Nano SKD STM32 Pocket-Sized 2Msps

US$ 60 - 80 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

DSO

Model Number:

DSO201

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

china

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name DSO

Model Number DSO201

2.8'' Pocket Oscilloscope ARM DSO201 DSO Nano SKD STM32 Pocket-Sized 2Msps

Display	2.8″ Color TFT LCD
Display Resolution	320×240
Display Color	65K
Analog bandwidth	0 - 1MHz
Max sample rate	1Msps 12Bits
Sample memory depth	4096 Point
Horizontal sensitivity	1uS/Div~10S/Div (1-2-5 Step)
Horizontal position	adjustable with indicator
Vertical sensitivity	10mV/Div~10V/Div (with ×1 probe)
	0.5V/Div~10V/Div (with ×10 probe)
Vertical position	adjustable with indicator
Input impedance	>500KΩ
Max input voltage	80Vpp (by ×1 probe)
Coupling	DC
Trig modes	Auto,Norma,Single,None and Scan
Functionalities:	Automatic measurement: frequency,cycle,duty,Vpp,Vram,Vavg and DC voltage
	Precise vertical measurement with markers
	Precise horizontal measurement with markers
	Rising/falling edge trigger
	Trig level adjustable with indicator
	Trig sensitivity adjustable with indicator
	Hold/run feature
Test signal	Built-in 10Hz~1MHz (1-2-5 Step)
Waveform storage	Micro SD card
PC connection via USB	as Micro SD card reader
Upgrade	by bootloader via USB
Power supply	3.7V Chargeable Lithium battery / USB
Dimension (w/o probe)	106mm X 55mm X 9.9mm
