Home > Instruments & Meters > Electronic Instrument > Oscilloscope > Handheld Digital Storage Oscilloscopes UTD2052CEX 50MHz 1GS/s 25 Kpts Memory Depth USB OTG Interface
Handheld Digital Storage Oscilloscopes UTD2052CEX 50MHz 1GS/s 25 Kpts Memory Depth USB OTG Interface
US$ 100 - 240
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTD2052CEX
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Handheld Digital Storage Oscilloscopes UTD2052CL 50MHz 500MS/s 25 Kpts Memory Depth USB OTG InterfaceUS$ 100 - 200MOQ: 1 Piece -
Handheld Digital Storage Oscilloscopes UTD2025CL 25MHz 500MS/s 25 Kpts Memory Depth USB OTG,Pass/Faill InterfaceUS$ 100 - 185MOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD2202CE 200MHz 1GS/s 25 Kpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 420MOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD2102CE 100MHz 1GS/s 25 Kpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 300MOQ: 1 Piece
-
Digital Storage Oscilloscopes UTD2062CE 60MHz 1GS/s 25 Kpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 270MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTD2052CEX
Handheld Digital Storage Oscilloscopes UTD2052CEX 50MHz 1GS/s 25 kpts Memory Depth USB OTG Interface
Detailed
1,Dual analog channels width range 1mV/div~20V/div;
2,7 inches widescreen LCD displays;
3,The new interface style;
4,Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
5,USB drive system software upgrade;
6,Storage of waveforms setups and interfaces waveforms and setups reproduction;
7,Automatic measurement of 32 waveform parameters;
8,Unique waveform recording and replay function;
9,Multilingual menu displays.
contrast
| Specification | UTD2052CEX | UTD2072CEX | UTD2102CEX |
| Channels | 2 | ||
| Bandwidth | 50MHz | 70MHz | 100MHz |
| Sample Rate | 1Gs/s | ||
| Rise Time | ≤7ns | ≤5ns | ≤3.5ns |
| Memory Depth | 25kpts | ||
| Waveform Acquisition Rate | ≥2000wfms/s | ||
| Vertical Sensitivity(V/div) | 1mV/div~20V/div | ||
| Timebase Range(s/div) | 2ns/div~50s/div | ||
| Storage | Setup,Wave,Bitmap | ||
| Trigger Modes | Edge, Pluse, Video,Slope,Alternate | ||
| Interface | USB OTG | ||
| General Characteristic | |||
| Power | 100-240VAC, 45-440Hz | ||
| Display | 7 Inches 64K Color TFT LCD, 800×480 | ||
| Product Color | White and Gray | ||
| Product Net Weight | 2.2 Kg | ||
| Product Size (W×H×D) | 306mm ×147mm × 122mm | ||
| Standard Accessories | Probe×2 (1×,10× switchable), Power Cord , USB Cable, PC Software CD | ||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 2 PCs | ||
| Standard Carton Measurement (L×W×H) | 450mm× 420mm × 280mm | ||
| Standard Carton Cross Weight | 8.5 Kg | ||
| Optional Accessories* | |||
| LA Module | |||
fitting
Probe×2 (1×,10× switchable),
Power Cord,
USB Cable,
PC Software CD,
LA Module (UT-M09)*
