Home > Instruments & Meters > Electronic Instrument > Oscilloscope > Handheld Digital Storage Oscilloscopes UTD2025CL 25MHz 500MS/s 25 Kpts Memory Depth USB OTG,Pass/Faill Interface
Handheld Digital Storage Oscilloscopes UTD2025CL 25MHz 500MS/s 25 Kpts Memory Depth USB OTG,Pass/Faill Interface
US$ 100 - 185
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTD2025CL
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Handheld Digital Storage Oscilloscopes UTD2202CE 200MHz 1GS/s 25 Kpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 420MOQ: 1 Piece -
Handheld Digital Storage Oscilloscopes UTD2102CE 100MHz 1GS/s 25 Kpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 300MOQ: 1 Piece
-
Digital Storage Oscilloscopes UTD2062CE 60MHz 1GS/s 25 Kpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 270MOQ: 1 Piece
-
Digital Storage Oscilloscopes UTD2025C 25MHz 250MS/s 25 Kpts Memory Depth USB Device, USB Host InterfaceNegotiableMOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD1050DL 2 Channels 50MHz 500MS/s 12kpts Memory Depth Mini USB InterfaceUS$ 100 - 360MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTD2025CL
Handheld Digital Storage Oscilloscopes UTD2025CL 25MHz 500MS/s 25 kpts Memory Depth USB OTG,Pass/Faill Interface
Detailed
1,Dual analog channels width range 1mV/div~20V/div;
2,7 inches widescreen LCD displays;
3,Special Print Scree Feature;
4,Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
5,USB drive system software upgrade;
6,Storage of waveforms setups and interfaces waveforms and setups reproduction;
7,Automatic measurement of 28 waveform parameters;
8,Unique waveform recording and replay function;
9,Multilingual menu displays.
contrast
| Specification | UTD2025CL | UTD2052CL |
| Channels | 2 | |
| Bandwidth | 25MHz | 50MHz |
| Sample Rate | 500Ms/s | 500Ms/s |
| Rise Time | ≤14ns | ≤7ns |
| Memory Depth | 25kpts | |
| Waveform Acquisition Rate | ≥2000wfms/s | |
| Vertical Sensitivity | 1mV/div~20V/div | |
| Timebase Range | 10ns/div~50s/div | 5ns/div~50s/div |
| Storage | Setup,Wave,Bitmap | |
| Trigger Modes | Edge, Pluse, Video, Alternate | Edge, Pluse, Alternate |
| Interface | USB OTG,Pass/Fail | USB OTG |
| General Characteristic | ||
| Power | 100-240VAC, 45-440Hz | |
| Display | 7 Inches 64K Color TFT LCD, 400×240 | |
| Product Color | White and Gray | |
| Product Net Weight | 2.2Kg | |
| Product Size (W×H×D) | 306mm × 134mm × 122mm | |
| Standard Accessories | Probe×2 (1×,10× switchable),Power Cord, USB Cable, PC Software CD | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 2 PCs | |
| Standard Carton Measurement (L×W×H) | 450mm × 420mm × 280mm | |
| Standard Carton Cross Weight | 8.3 Kg | |
fitting
Probe×2 (1×,10× switchable),
Power Cord,
USB Cable,
PC Software CD
