Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UTD2202CE |
Product Description
Handheld Digital Storage Oscilloscopes UTD2202CE 200MHz 1GS/s 25 kpts Memory Depth USB Device, USB Host, Pass/Fail Interface
Detailed
1,Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
2,Storage of waveforms setups and interfaces waveforms and setups reproduction;
3,Automatic measurement of 28 waveform parameters;
4,Unique waveform recording and replay function;
5,Edge,Pluse,Video,Alternate trigger functions;
6,Unique Pass/Fail functions;
7,Multilingual menu displays.
contrast
| Specification | UTD2102CE | UTD2152CE | UTD2202CE2 |
| Channels | 2 | ||
| Bandwidth | 100MHz | 150MHz | 200MHz |
| Sample Rate | 1GS/s | ||
| Rise Time | ≤3.5ns | ≤2.3ns | ≤1.8ns |
| Memory Depth | 25kpts | ||
| Waveform Acquisition Rate | ≥2000wfms/s | ||
| Vertical Sensitivity | 2mV/div~5V/div | ||
| Timebase Range | 5ns/div~50s/div | 2ns/div~50s/div | |
| Storage | Setup, Wave, Bitmap | ||
| Trigger Modes | Edge, Pluse, Video, Alternate | ||
| Interface | USB Device, USB Host, Pass/Fail | ||
| General Characteristic | |||
| Power | 100-240VAC, 45-440Hz | ||
| Display | 5.7 Inches 64K Color TFT LCD, 320×240 | ||
| Product Color | White and Gray | ||
| Product Net Weight | 2.5 Kg | ||
| Product Size(W×H×D) | 320mm ×150mm ×130mm | ||
| Standard Accessories | Probe×2 (1×,10× switchable),Power Cord, USB Cable, PC Software CD | ||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 2 PCs | ||
| Standard Carton Measurement(L×W×H) | 450mm × 420mm × 280mm | ||
| Standard Carton Cross Weight | 9.2 Kg | ||
| Optional Accessories | |||
| LAN Communication Port, | |||
fitting
Probe×2 (1×,10× switchable),
Power Cord,
USB Cable,
PC Software CD,
LAN Communication Port*
