Help CenterUNI-T UTD4302C 300MHz 2GSa/s AC110-220V 2 Channels Bench Digital Oscilloscope
Related Products
-
OWON HDS1021M-N 1-ch Display Single Channel /Digital Storage Handheld Oscilloscope,3.5 Inch LCD, 20MHz 500MS/sNegotiableMOQ: 1 Piece -
Digital Storage Oscilloscopes UTD4202C 200MHz 2GS/s 24 Mpts Memory Depth USB Device, USB Host, Pass/Fail, LA Interface,NegotiableMOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD4102C 100MHz 2GS/s 24 Mpts Memory Depth USB Device, USB Host, Pass/Fail, LA Interface,NegotiableMOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD2202CM 200MHz 1GS/s 16 Mpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 530MOQ: 1 Piece
-
UTD2102CM 100MHZ 1GS/s Digital Storage Oscilloscope 7" TFT LCD Dual Channels USBNegotiableMOQ: 1 Piece
Digital Storage Oscilloscopes UTD4302C 300MHz 2GS/s 24Mpts Memory Depth USB Device, USB Host, Pass/Fail, LA Interface, Multimeter Interface
Detailed
1,2GS/s real-time sampling rate;
2,Dual time base function; unrivaled waveform detail observation and analysis capabilities;
3,16-channel logic analyzer; 3½ digital multimeter;
4,Unique envelop sampling feature with direct visual display of carrier wave details after amplitude modulation;
5,Quick waveform acquisition and colour change function that visually describes the strength of waveform;
6,Supports plug-and-play USB storage devices and capable of communicating with a computer;
7,USB drive system software upgrade;
8,Built-in FFT and Multiple waveform mathematics functions (including add, subtract, multiply and divide);
9,Edge, Video, Pulse Slop and Alternate trigger functions.
contrast
| Specification | UTD4062C | UTD4102C | UTD4202C | UTD4302C | |
| Channels | 2 | ||||
| Bandwidth | 60MHz | 100MHz | 200MHz | 300MHz | |
| Sample Rate | 2GS/s | ||||
| Rise Time | ≤5.8ns | ≤3.5ns | ≤1.8ns | ≤1.2ns | |
| Memory Depth | 24kpts | ||||
| Waveform Acquisition Rate | ≥2,000wfms/s | ||||
| Vertical Sensitivity | 1mV/div~10V/div | ||||
| Timebase Range | 5ns/div~50s/div | ||||
| Storage | Setup, Wave, Bitmap, CSV | ||||
| Trigger Modes | Edge, Pluse, Video, Slope, Alternate, LA | ||||
| Interface | USB Device, USB Host, Pass/Fail, LA Interface, Multimeter Interface | ||||
| Multimeter Specifications | Range | Best Accuracy | |||
| DC Voltage (V) | 400mV, 4V, 40V, 400V | ± (1% + 5) | |||
| AC Voltage (V) | 4V, 40V, 400V | ± (1.2% + 5) | |||
| DC Current (A) | 4mA, 40mA, 400mA, 4A | ± ( 1% + 5) | |||
| (External Convertor) | 4A: ± ( 1.5% + 5) | ||||
| Resistance (Ω) | 400Ω, 4kΩ , 40kΩ , 400kΩ , 4MΩ , 40MΩ | ± ( 1.5% + 5) | |||
| Display Count | 4000 | ||||
| Auto Range | √ | ||||
| General Characteristic | |||||
| Power | 100-240VAC, 45-440Hz | ||||
| Display | 5.7 Inches 64K Color TFT LCD, 320×240 | ||||
| Product Color | White and Gray | ||||
| Product Net Weight | 3.8 Kg | ||||
| Product Size (W×H×D) | 337mm × 190mm × 180mm | ||||
| Standard Accessories | Probe×2 (1×,10× switchable), Logic Analyzer Probe, Current-to-Voltage Convertor , Test Leads, Power Cord, USB Cable, PC Software CD | ||||
| Standard Individual Packing | Gift Box, English Manual | ||||
| Standard Quantity Per Carton | 2 PCs | ||||
| Standard Carton Measurement(L×W×H) | 540mm × 425mm × 325mm | ||||
| Standard Carton Cross Weight | 13.7 Kg | ||||
| Optional Accessories* | |||||
| LAN Port, GPIB Port | |||||
Fitting
Probe×2 (1×,10× switchable),
Logic Analyzer Probe,
Current-to-Voltage Convertor Module,
Test Leads,
Power Cord,
USB Cable,
PC Software CD,
LAN Communication Port*,
GPIB Port*
