Home > Instruments & Meters > Electronic Instrument > Oscilloscope > Handheld Digital Storage Oscilloscopes UTD2202CM 200MHz 1GS/s 16 Mpts Memory Depth USB Device, USB Host, Pass/Fail Interface
Handheld Digital Storage Oscilloscopes UTD2202CM 200MHz 1GS/s 16 Mpts Memory Depth USB Device, USB Host, Pass/Fail Interface
US$ 100 - 530
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTD2202CM
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UTD2102CM 100MHZ 1GS/s Digital Storage Oscilloscope 7" TFT LCD Dual Channels USBNegotiableMOQ: 1 Piece -
Handheld Digital Storage Oscilloscopes UTD2062CM 60MHz 1GS/s 16 Mpts Memory Depth USB Device, USB Host, Pass/Fail InterfaceUS$ 100 - 360MOQ: 1 Piece
-
Uni-T UTD2102CEX 1G Digital 7" TFT LCD 2-Channel Storage Oscilloscope 100MHz Upgrated From UTD2102CELNegotiableMOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD2052CEX 50MHz 1GS/s 25 Kpts Memory Depth USB OTG InterfaceUS$ 100 - 240MOQ: 1 Piece
-
Handheld Digital Storage Oscilloscopes UTD2052CL 50MHz 500MS/s 25 Kpts Memory Depth USB OTG InterfaceUS$ 100 - 200MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTD2202CM
Handheld Digital Storage Oscilloscopes UTD2202CM 200MHz 1GS/s 16Mpts Memory Depth USB Device, USB Host, Pass/Fail Interface
Detailed
1,Dual analog channels width range 1mV/div~20V/div;
2,7 inches widescreen LCD displays;
3,The new interface style;
4,Supports plug-and-play USB storage device. Communication with and remote control of computer through the USB device;
5,USB drive system software upgrade;
6,Storage of waveforms setups and interfaces waveforms and setups reproduction;
7,Automatic measurement of 32 waveform parameters;
8,Unique waveform recording and replay function;
9,Multilingual menu displays.
contrast
| Specification | UTD2062CM | UTD2102CM | UTD2202CM |
| Channels | 2 | 2 | 2 |
| Bandwidth | 60MHz | 100MHz | 200MHz |
| Sample Rate | 1GS/s | ||
| Rise Time | ≤5.8ns | ≤3.5ns | ≤1.8ns |
| Memory Depth | 16Mpts | ||
| Waveform Acquisition Rate | ≥150,000wfms/s | ||
| Vertical Sensitivity | 2mV/div~10V/div | ||
| Timebase Range | 2ns/div~50s/div | ||
| Storage | Setup, Wave, Bitmap, CSV | ||
| Trigger Modes | Edge, Pluse, Video, Slope, Alternate | ||
| Interface | USB Device, USB Host, Pass/Fail | ||
| General Characteristic | |||
| Power | 100-240VAC, 45-440Hz | ||
| Display | 7 Inches 64K Color TFT LCD, 800×480 | ||
| Product Color | White and Gray | ||
| Product Net Weight | 2.9 Kg | ||
| Product Size(W×H×D) | 330mm × 155mm × 130mm | ||
| Standard Accessories | Probe×2(1×,10× switchable),Power Cord,USB Cable,PC Software CD | ||
| Standard Individual Packing | Gift Box, English Manual | ||
| Standard Quantity Per Carton | 2 PCs | ||
| Standard Carton Measurement(L×W×D) | 450mm × 420mm × 280mm | ||
| Standard Carton Cross Weight | 10 Kg | ||
| Optional Accessories* | |||
| LAN Port, LA Module | |||
fitting
Probe×2 (1×,10× switchable),
Power Cord,
USB Cable,
PC Software CD,
LA Module (UT-M09)*
(Julie Zhou)
