UNI-T UT71E Intelligent LCD Digital Multimeter With USB Interface Frequency Tester Meter
US$ 160 - 200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT71E
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Bench Multimeters,Multimeters,Digital AC Milli Volt Meters,Handheld Digital Multimeters,Automotive MultimetersUS$ 1 - 2MOQ: 1 Piece -
RIGOL DM3058E 5 1/2 Digit Digital MultimeterUS$ 748 - 768MOQ: 1 Piece
-
RIGOL DM3058 - 5 1/2 Digit Digital MultimeterUS$ 1,108 - 1,148MOQ: 1 Piece
-
Brand New Rigol DM3068 6 1/2 Digital MultimeterUS$ 1,478 - 1,518MOQ: 1 Piece
-
ADM01 Auto Ranging Digital Multimeter DMM DC AC Voltage Current HZ Meter Frequency Tester Diode Continuity TestUS$ 10 - 20MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT71E
Dimensions
200 x 93 x 40mm
UNI-T UT71E Intelligent LCD Digital Multimeter With USB Interface Frequency Tester Meter
SPECIFICATIONS
| Basic Functions | Range | Best Accuracy |
|---|---|---|
| DC Voltage | 400mV/4V/40V/400V/1000V | ±(0.025%+5) |
| AC Voltage | 4V/40V/400V/1000V | ±(0.4%+30) |
| AC Bandwidth | 100KHz | √ |
| DC Current | 400µA/4000µA/40mA/400mA/10A | ±(0.08%+8) |
| AC Current | 400µA/4000µA/40mA/400mA/10A | ±(0.5%+15) |
| Resistance | 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ | ±(0.3%+8) |
| Capacitance | 40nF/400nF/4µF/40µF/400µF/4mF/40mF | ±(1%+20) |
| Temperature (°C) | -40°C ~ 1000°C | ±(1%+30) |
| Temperature (°F) | -40°F ~ 1832°F | ±(1.5%+50) |
| Frequency | 40Hz/400Hz/4kHz/40kHz/400kHz/4MHz/40MHz/400MHz | ±(0.01%+8) |
| Duty Cycle | 10%~90% | ±(1%+30) |
| 4~20mA Loop | 0~100% | ±(1%+50 |
| Power Measurement | ±(2%+5) | |
| Special Functions | ||
| Fused 10A Range | √ | |
| Auto Ranging | √ | |
| Current Measurement Alarm | √ | |
| Function Set Up | √ | |
| Auto Ranging | √ | |
| Votage & Current : AC + DC Measurement |
√ | |
| Data Logging | 100 | |
| Data Recall | √ | |
| Diode | √ | |
| Continuity Buzzer | √ | |
| True RMS | √ | |
| Peak Hold | √ | |
| Max/Min Mode | √ | |
| Relative Mode | √ | |
| Data Hold | √ | |
| USB | √ | |
| Double Display Backlight | √ | |
| Full Icon Display | √ | |
| Sleep Mode | √ | |
| Low Battery Display | √ | |
Input Impedance for |
DC 200mV : Around 2.5GΩ All Other Ranges : 10MΩ |
√ |
| Max. Display | 40000 | √ |
| Analogue Bar Graph | √ |
GENERAL CHARACTERISTICS
| Power | 9V Battery (6F22) |
| LCD Size | 73 x 50 mm |
| Product Colour | Red and Grey |
| Product Net Weight | 384g |
| Product Size | 200 x 93 x 40mm |
| Standard Accessories | Test Lead, English Manual, Battery, Alligator Clip, USB Interface Cable, Software, Point Contact Temperature, Probe, Carrying Bag, Test Clip |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 20 pcs |
| Standard Carton Measurement | 542 x 376 x 388mm |
| Standard Carton Gross Weight | 18kg |
