Specifications
RIGOL DM3058E 5 1/2 Digit Digital Multimeter
RIGOL DM3058E 5 1/2 Digit Digital Multimeter
Product Description:
DM3058E
The difference between DM3058 and DM3058E is only that DM3058E doesn’t support LAN and GPIB interfaces.
The Model DM3058 DMM gives reliable, cost effective, full DMM capabilities measuring DCV, ACV, DCI, ACI, Resistance (2 & 4 Wire), Capacitance, Diode Test, Frequency, and Temperature. These DMMs are designed for simple and efficient bench top use, but include software options for datalogging and remote programming from almost any interface. The DM3058 is a great bench tool for basic, reliable measurements regardless of your application or need.
Main Features:
Real 5½digits readings resolution
Up to 123 rdgs/s measurement speed
True-RMS AC Voltage and AC Current measuring
Quickly Save or Recall the 10 groups of Preset Configuration
Preset 10 groups of Standard Sensor Configuration, built-in cold terminal compensation for thermocouple
Clone the instrument configurations into other DM3058/DM3058E via USB storage device
The first 5 ½digit digital multimeter passing LXI Criterion in industry, which can achieve system integration easily
With easy, convenient and flexible any sensor measurement control software: UltraSensor
Standard configuration interface: USB Device, USB Host, LAN (only for DM3058), RS-232, GPIB (only for DM3058)
Support remote control via commands and compatible with commands of main stream multimeters
256x64 LCD
Support double display, Chinese and English menu
Built-in help system makes information acquisition more easier
File management (support for U-disc and local storage)
Basic Measurement Function:
DC Voltage: 200 mV - 1000 V
DC Current: 200 uA - 10 A
AC Voltage: True-RMS, 200 mV - 750 V
AC Current: True-RMS, 20 mA - 10 A
2-Wire, 4-Wire Resistance: 200 Ohm - 100 MOhm
Capacitance Measurement: 2 nF - 10000 uF
Continuity Test: Range is fixed at 2 kOhm
Diode Test: Range is fixed at 2.0 V
Frequency Measurement: 20 Hz - 1 MHz
Period Measurement: 1 us - 0.05 s
Any Sensor Measurement: Support for 6 types of sensor (DCV, DCI, Freq, 2WR, 4WR and TC)
Edited By Evan
